HGA260301 | Square D 30A 2-Pole 600VAC PowerPact H I-Line Thermal Magnetic Circuit Breaker
- Regular price
- $799.00
- Sale price
- $799.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: HGA260301
Description
The Square D HGA260301 is a 2-pole thermal magnetic molded case circuit breaker rated at 30 amps and 600 VAC. It provides reliable overload and short-circuit protection using long-time and instantaneous trip functions. Designed with an I-Line plug-in connection, it ensures fast installation and high performance in commercial and industrial power distribution systems.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Square D |
| Category | Circuit Protection |
| Part Number | HGA260301 |
| Subcategory | 2-Pole Molded Case Circuit Breaker |
| Series | PowerPact H |
| Frame Type | HGA |
| Amperage Rating | 30A |
| Voltage Rating | 600 VAC / 250–500 VDC |
| Interrupting Rating | 35 kA @ 480 VAC; 65 kA @ 240 VAC; 18 kA @ 600 VAC; 20 kA @ 250–500 VDC |
| Poles | 2 |
| Phase | Single Phase |
| Trip Unit Type | Thermal Magnetic (LI – Long-Time & Instantaneous) |
| Mounting Type | I-Line Plug-In |
| Connection Type | I-Line (Line Side), Load Lug (Load Side) |
| Wire Range | AWG 14–3/0 Aluminum or Copper |
| Control Type | Toggle |
| Temperature Rating | -25°C to +70°C (-13°F to +158°F) |
| Standards & Approvals | UL, CSA, CE, NEMA, NOM, IEC 60947-2 |
| Protection Degree (Front Cover) | IP40 |
| Dimensions (H × W × D) | 6.4 × 4.09 × 3.4 in (163 × 104 × 86 mm) |
| Country of Origin | Mexico |
| Weight | 4.85 lb (2.2 kg) |
Information About HGA260301
The HGA260301 is part of Square D’s PowerPact H series, known for its high breaking capacity and compact molded case design. It features an H-frame thermal-magnetic trip unit that offers precise long-time and instantaneous protection against overcurrent and short-circuit events. The breaker integrates seamlessly into I-Line distribution panels, providing plug-in convenience and compatibility with standard Square D accessories and lugs. Built to UL, CSA, and IEC standards, it ensures dependable performance for distribution and control applications in demanding environments.
Key Features:
- High Interrupting Capacity: Handles up to 35 kA at 480 VAC and 65 kA at 240 VAC for enhanced safety.
- Thermal Magnetic Trip Unit: Combines long-time and instantaneous trip functions for reliable circuit protection.
- I-Line Plug-In Mounting: Enables quick, secure installation in I-Line panelboard systems.
- Durable H-Frame Construction: Provides strong mechanical endurance for industrial environments.
- Wide Voltage Range: Supports 600 VAC and 250–500 VDC applications.
- Comprehensive Standards Compliance: Meets UL 489, CSA, NOM, CE, and IEC 60947-2 certifications.
- Temperature Tolerance: Operates efficiently between -25°C and +70°C (-13°F to +158°F).
- HACR Rated: Suitable for use in heating, air-conditioning, and refrigeration systems.
The HGA260301 delivers the reliability and precision required for safe and consistent performance in power distribution and control systems.
