101609-01 | Lennox HVAC Timer Board Blower Delay Control Module
- Regular price
- $419.00
- Sale price
- $419.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: 101609-01
Description
The Lennox 101609-01 Timer Board is a control module designed to manage timed blower and system functions in Lennox HVAC equipment. It provides precise timing control to coordinate fan operation during heating and cooling cycles. This board is used to ensure proper airflow sequencing and system efficiency in residential HVAC systems.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Lennox |
| Category | HVAC Control Boards |
| Part Number | 101609-01 |
| Subcategory | Timer Control Boards |
| Board Type | HVAC Timer Board |
| Control Voltage | 24 V |
| Function | Blower On/Off Delay Timing |
| Application | Residential HVAC Systems |
| Compatible Brand | Lennox |
| Mounting Type | Internal Furnace / Air Handler Mount |
| Construction | Electronic Control Board |
| Duty Cycle | Continuous Operation |
| Weight | Approx. 0.5 lb (0.23 kg) |
Information About 101609-01
The 101609-01 is a Lennox timer control board used in gas furnaces and air handling equipment to regulate blower on-delay and off-delay functions. It is engineered to improve comfort and system performance by ensuring correct airflow timing after burner shutdown or during startup. The board integrates directly into compatible Lennox control systems using standard low-voltage connections. Its electronic design supports reliable operation and long service life in residential HVAC environments.
Key Features:
- HVAC Timer Control Board: Regulates timed blower and system control functions.
- Lennox OEM Component: Designed for compatibility with Lennox HVAC equipment.
- Blower Delay Control: Manages fan on-delay and off-delay sequencing.
- 24V Control Circuit Operation: Compatible with standard low-voltage HVAC systems.
- Improved Airflow Management: Enhances comfort and heat exchanger efficiency.
- Electronic Timing Accuracy: Provides consistent and repeatable timing performance.
- Compact Board Design: Fits easily within furnace and air handler control compartments.
- Service Replacement Board: Ideal for restoring proper system timing functions.
- Durable Control Electronics: Built to withstand electrical and thermal stresses in HVAC environments.
The 101609-01 delivers the reliability and precision required for timed blower control and HVAC system operation.
