1326AB-B530E-21-K5 | Allen-Bradley Servo Motor
- Regular price
- $8,999.00
- Sale price
- $8,999.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 1326AB-B530E-21-K5
Description
The 1326AB-B530E-21-K5 is a high-performance AC servo motor from Allen-Bradley’s 1326AB series. It features a NEMA frame, provides continuous torque output, and includes a resolver feedback system for precise position control.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Allen-Bradley |
| Category |
Servo Products
|
| Part Number | 1326AB-B530E-21-K5 |
| Subcatecory |
Servo Motor
|
| Voltage | 460/380V AC |
|
Frame Diameter |
149 mm |
| Rated Motor Speed | 3000 rpm @ 460VAC; 2500 @ 380VAC |
| Flange and Shaft Series | IEC Metric Flange with Keyway |
| Motor Rated Torque | 18.0 Nm |
| Motor Rated Output | 4.2 kW |
| Standard Option | 13.6 Nm Holding Brake w/ 24V DC Coil. |
| System Continuous Torque | 18.0 Nm |
| System Peak Stall Torque | 54.2 Nm |
| Weight | 85.15 lbs |
Information About 1326AB-B530E-21-K5
The 1326AB-B530E-21-K5 is a three-phase brushless AC servo motor from the Allen-Bradley 1326AB Torque Plus Series, designed for high-performance motion control applications. It delivers precise torque and speed control using resolver feedback and includes an integrated holding brake for enhanced safety. This motor is engineered for demanding industrial environments requiring accurate and responsive servo operation.
Key Features:
- Continuous Torque: 18 Nm
- Rated Power Output: 4.2 kW
- Voltage: 460V AC, three-phase
- Maximum Speed: 3000 RPM
- Frame Size: 149 mm diameter (IEC metric frame)
- Mounting: IEC metric flange with keyway
- Feedback Device: Resolver
- Brake: 13.6 Nm holding brake, 24V DC
- Cooling Method: Natural convection (TENV)
- Construction: Rugged industrial-grade housing
- Protection Class: Typically IP65 (based on enclosure)
- Application: High-performance servo systems, positioning and load-holding tasks
Ideal for use in coordinated motion, robotics, material handling, and other dynamic automation applications, the 1326AB-B530E-21-K5 ensures precise control, high reliability, and seamless integration with Allen-Bradley Ultra™ or 1394 servo drive systems.
