Part #: 1336-MOD-KB010 Manufactured by: Allen-Bradley
$2,439.50
$2,439.50
6 in Stock
Condition: New – Open box
Shipping calculated at checkout.
Product Overview
The Allen-Bradley 1336-MOD-KB010 is a Heavy Duty Dynamic Brake designed for use with 380-480V AC systems, with a maximum r...  Read more
We accept:
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Venmo
  • Visa

Do you need help?

Call our Sales Manager
phone
+1 (828) 222-3490
Mon./Sat.: 7:00AM - 8:00PM
Write to us now
email
sales@iqelectro.com
Mon./Sat.: 7:00AM - 12:00PM
warranty
IQElectro 2-Year Warranty
Warranty for Product #: 1336-MOD-KB010
IQElectro offers a free 2-year warranty on all products. You can trust that every purchase is a reliable investment in the future of your company. Warranty Terms
2-3 Day Free Shipping
Packed Ready to Ship
24/7 Expert Support
Return within 30-Days
IQElectro is Not an authorized distributor for Allen-Bradley
Original Manufacturer's Warranty Not Covered, This Product is SURPLUS.

Product Description P/N: 1336-MOD-KB010

Description / Specifications

Description

The Allen-Bradley 1336-MOD-KB010 is a replacement keypad and display module designed for use with 1336 series AC drives. It provides an operator interface for drive programming, monitoring, and parameter adjustment.





Technical Specifications

Condition New/Never Used Surplus
Brand Allen Bradley
Category Brake Systems
Part Number 1336-MOD-KB010
Subcategory Dynamic Brakes
Product Line 1336 Adjustable
Top Category Motors & Motor Controls
Description Heavy-duty dynamic braking option
Enclosure Type NEMA Type 1
Voltage Rating 380/415/460 V AC
Frequency Rating 50/60 Hz
Drive Compatibility 1336 series B007–B010
Power Rating 10 HP / 750 W
Equivalent To Same as 163019
Product Lifecycle Status Discontinued/Obsolete (discontinued 06/25/2010)
Function Dynamic brake module for AC drives
Weight 16.31 lbs (7.40 kg)





Information About 1336-MOD-KB010

The 1336-MOD-KB010 is part of the Allen-Bradley 1336 MOD series of accessories, developed to extend and maintain the functionality of 1336 variable frequency drives. This keypad/display module enables local operator control, allowing users to start, stop, and configure the drive as well as view operational parameters and fault diagnostics. Featuring a simple navigation layout with an alphanumeric display, it ensures efficient drive setup and monitoring. The 1336-MOD-KB010 is designed as a direct replacement for original keypad modules, ensuring compatibility and restoring functionality without the need for drive replacement. It is an essential component for sustaining long-term operation of legacy 1336 drive installations.

Key Features:

  • Design: Replacement keypad and display module for 1336 series drives.
  • Functionality: Provides local operator interface for control, setup, and monitoring.
  • Display: Alphanumeric display with clear status and fault indication.
  • Compatibility: Designed specifically for Allen-Bradley 1336 variable frequency drives.
  • Ease of Use: Intuitive keypad layout for efficient navigation and parameter editing.
  • Maintenance: Direct replacement part to restore full operator control to legacy drives.
  • Reliability: Built for long service life in industrial environments.
  • Application Range: Suitable for commissioning, maintenance, and troubleshooting of AC drives.

The 1336-MOD-KB010 delivers the interface and reliability required for effective operation and support of Allen-Bradley 1336 drive systems.

Frequently Asked Questions about 1336-MOD-KB010
Question: What type of enclosure does the 1336-MOD-KB010 have?
Date Update:26/05/2025
Answer:

The 1336-MOD-KB010 is built into a NEMA Type 1 enclosure, which is designed for indoor environments. It provides basic protection against dust and incidental contact but is not intended for wet or outdoor conditions. Proper installation in a dry control room or electrical cabinet is necessary to ensure safe and reliable operation.

Question: How should the 1336-MOD-KB010 be installed?
Date Update:26/05/2025
Answer:

This braking unit must be mounted vertically to allow proper airflow across the resistive elements. It should be installed outside of any drive enclosure and requires a minimum clearance of 304.8 mm (12 inches) from any adjacent unit, including the drive itself. Adequate ventilation is essential to prevent overheating and ensure long-term performance.

Question: What is the braking resistance of the 1336-MOD-KB010?
Date Update:26/05/2025
Answer:

When paired in parallel with the 1336-MOD-KB050 unit, the effective braking resistance is approximately 8.76 Ohms. This resistance value determines how much electrical energy is dissipated during braking. A lower resistance value allows more energy to be absorbed, resulting in faster and more powerful deceleration.

Question: What are the dimensions and weight of the 1336-MOD-KB010?
Date Update:26/05/2025
Answer:

The unit measures 28 x 24 x 20 inches and weighs approximately 25 pounds (11.3 kg). These physical characteristics must be considered when designing the control cabinet layout or mounting location. Adequate space and mounting strength are required due to its size and weight.

Question: Can multiple 1336-MOD-KB010 units be used together?
Date Update:26/05/2025
Answer:

Yes, multiple 1336-MOD-KB010 braking assemblies can be connected in parallel when the braking current demand exceeds the capacity of a single unit. In such setups, one unit is designated as the master, while additional units function as followers, synchronizing braking effort. This allows for scalable dynamic braking tailored to high-power motor applications.
