140-DDI-353-00 | Schneider Electric Discrete Input Module Modicon Quantum - 32 I 24 V DC
- Regular price
- $508.00
- Sale price
- $508.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 140-DDI-353-00
Description
The Schneider Electric 140-DDI-353-00 is a 32-point DC discrete input module designed for the Modicon Quantum automation platform. It provides reliable 24 VDC sink-type input processing, making it suitable for monitoring switches, sensors, and other digital field devices in industrial control systems. Built for demanding environments and critical processes, this module ensures stable and accurate signal acquisition in manufacturing, utilities, and large-scale automation applications.
Technical Specifications
| Condition | New / Never Used Surplus |
| Brand | Schneider Electric |
| Category | Discrete Input Modules |
| Part Number | 140-DDI-353-00 |
| Subcategory | Quantum DC Input Module |
| Product Range | Modicon Quantum |
| Input Type | 24 VDC discrete, sink (positive logic) |
| Number of Inputs | 32 |
| Groups of Channels | 4 |
| Input Voltage | 24 VDC |
| Input Voltage Limits | 19.2…30 VDC |
| Voltage State 1 Guaranteed | 15…30 VDC |
| Voltage State 0 Guaranteed | −3…5 VDC |
| Current State 1 Guaranteed | ≥ 2 mA |
| Current State 0 Guaranteed | ≤ 0.5 mA |
| Input Impedance | 2500 Ω |
| Leakage Current | 200 mA (specific conditions) |
| Absolute Max Input | 56 V (1.3 ms pulse), 30 V continuous |
| Response Time | ≤ 1 ms (state changes) |
| Protection Type | Resistor limited |
| Power Dissipation | 1.7 W + 0.36 W ⚊ per active channel |
| Local Signalling | 32 green LEDs, 1 red fault LED, 1 green communication LED |
| Bus Current Requirement | 330 mA |
| Isolation (Group–Bus) | 1780 Vrms for 1 min |
| Isolation (Group–Group) | 500 Vrms for 1 min |
| Module Format | Standard |
| Product Weight | 0.3 kg |
| Operating Temperature | 0…60 °C |
| Storage Temperature | −40…85 °C |
| Relative Humidity | 95% non-condensing |
| Operating Altitude | ≤ 5000 m |
| Standards | CSA C22.2 No.142, UL 508 |
| Certifications | ABS, BV, C-Tick, DNV, GOST, RINA, RMRS |
Information About 140-DDI-353-00
The 140-DDI-353-00 forms part of the Modicon Quantum family, a high-performance PLC platform widely used in complex industrial automation. This module offers 32 DC input channels arranged in four groups, supporting 24 VDC positive (sink) logic. It includes resistor-limited input protection and supports input voltage ranges from 19.2 to 30 VDC, ensuring compatibility with a wide variety of field devices. Designed for robust operation, it features fast response times of less than 1 ms, 2500-ohm input impedance, and built-in diagnostics such as fuse status and communication LEDs. The module provides strong electrical isolation—1780 Vrms between bus and group, and 500 Vrms between groups—enhancing system reliability. With global industrial certifications and rugged environmental resistance, it integrates seamlessly into Quantum racks for long-term, mission-critical applications.
Key Features:
- 32 Discrete DC Inputs: Ideal for high-density signal monitoring in Quantum PLC systems.
- 24 VDC Sink Logic: Supports positive logic with guaranteed state levels for reliable operation.
- Four Input Groups: Organized for flexible wiring and distributed field device connection.
- Fast Response Time: Less than 1 ms from state 0→1 or 1→0.
- Input Protection: Resistor-limited protection against over-voltage and electrical faults.
- High Isolation Ratings: 1780 Vrms (group-to-bus) and 500 Vrms (group-to-group) for enhanced safety.
- LED Diagnostics: Includes 32 green input status LEDs, a red fault LED, and communication indicators.
- Wide Environmental Tolerance: Operates in temperatures from 0…60 °C with strong ESD and EMC protection.
- Quantum Platform Integration: Fully compatible with Modicon Quantum backplanes and addressing schemes.
- Global Approvals: Certified for ABS, BV, DNV, GOST, C-Tick, UL, CSA, RINA, and RMRS.
The 140-DDI-353-00 delivers high-density digital input capability with the durability required for industrial automation environments.
