140DAI54000 | Schneider Electric Discrete input module
- Regular price
- $379.00
- Sale price
- $379.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 140DAI54000
Description
AC digital input module - Schneider Electric / Modicon (Modicon Quantum series) - 16I/Os [16DI (16 x digital inputs (115Vac; 16 x 1 input; isolated inputs with no common point))] - Supply voltage 93-138Vac (115Vac nom.) - backplane / rack mounting - with 40-pin screw term. blck. (sold separately) - Rated for +32...+140°F / 0...+60°C ambient
Technical Specifications
| Brand | Schneider Electric |
| Part Number | 140DAI54000 |
| Category | PLCs/Machine Control |
| Subcategory | PLC Module/Rack |
| Type | I/O Modules |
| Module format | Standard |
| Range of product | Modicon Quantum automation platform |
| Product or component type | VAC discrete input modules |
| Software name | Concept ProWORX 32 Unity Pro |
| Discrete input number | 16 |
| Group of channels | 16 |
| Addressing requirement | 1 input word |
| Discrete input voltage | 115 V AC |
| Input current | <= 13.2 mA 47...53 Hz <= 11.1 mA 57...63 Hz |
| Voltage state1 guaranteed | 85...132 V AC at 47...53 Hz 79...132 V AC at 57...63 Hz |
| Voltage state 0 guaranteed | 0...20 V AC at 47...53 Hz 0...20 V AC at 57...63 Hz |
| Input impedance | 14400 Ohm capacitive at 47...53 Hz 12000 Ohm capacitive at 57...63 Hz |
| Network frequency limits | 47...63 Hz |
| Leakage current | <= 2.1 mA |
| Absolute maximum input | 200 V 1 cycle 156 V 10 s 132 V continuous |
| Response time | 7.3...12.3 ms On-Off 4.9...0.75 ms x line cycle Off-On |
| Isolation between channels | 1780 Vrms for 1 minute |
| Isolation between channels and bus | 1780 Vrms for 1 minute |
| Bus current requirement | 180 mA |
| Power dissipation in W | <= 5.5 W |
| Local signalling | 16 LEDs green input status 1 LED red external fault detected (F) 1 LED green bus communication is present (Active) |
Information About 140DAI54000
The Modicon Quantum discrete input module 140 DAI 540 00 is manufactured by Schneider Electric for use on the Modicon Quantum automation platform. The Modicon 140 DAI 540 00 16 x I - 115 V AC module with 16 discrete input channels. The Quantum input module is compatible with Concept, ProWORX 32, and Unity Pro software.
Features of the Modicon Quantum 140 DAI 540 00
The Modicon Quantum 140 DAI 540 00 offers a group of 16 channels with 1 input word addressing. The input current for the Quantum 140 DAI 540 00 module is 11.1 mA 57...63 Hz and 13.2 mA 47...53 Hz. The discrete input voltage for this unit is 115 V AC. The guaranteed state one voltage for the 140 DAI 540 00 is 79...132 V AC 57...63 Hz and 85...132 V AC 47...53 Hz. The zero guarantee voltage state for the Quantum 140 DAI 540 00 is 0...20 V AC, 57...63 Hz, and 0...20 V AC, 47...53 Hz. The input impedance for this module is 12000 Ohm capacitive, 57...63 Hz, and 14400 Ohm capacitive, 47...53 Hz. The network frequency limits are between 47…63 Hz. The max leakage current is 2.1 mA. The absolute maximum input for the Modicon Quantum 140 DAI 540 00 is 132 V continuous, 156 V 10 s, 200 V 1 cycle with a response time of 4.9...0.75 ms x line cycle Off-On and 7.3...12.3 ms On-Off. The isolation between channels is 1780 Vrms for 1 minute and the isolation between channels and bus is 1780 Vrms for 1 minute. The bus current requirement for the Modicon Quantum discrete input module 140 DAI 540 00 is 180 mA. The maximum power dissipation is 5.5 W.
Local signaling for the Modicon Quantum 140 DAI 540 00
The 140 DAI 540 00 Modicon Quantum discrete input module is equipped with LED indicators one through sixteen. The ACTIVE LED indicates green when the unit is ON and bus communication is present. LED indicators one through sixteen indicate green when an indicated point or channel is turned ON.
Presentation
The Modicon Quantum 140 DAI 540 00 displays the color-coded module number and description at the top front of the module. The LED signaling is below the module number on the front panel. Inside a hinged door is the fuse cutout area that houses the field wiring terminal strip. The field wiring terminal strip is a separate item and must be ordered separately. There is spaced inside the hinged door that covers the field wiring strip and fuse cutouts for a customer identification label that you fold and place inside. This label is used to store customer-specific information.
Manufacturer information
Schneider Electric, a global leader in energy management and automation, offers innovative solutions for efficiency and sustainability. With a diverse portfolio spanning power distribution, automation, and renewable energy, Schneider Electric is committed to shaping a more connected and sustainable future.
Description
AC digital input module - Schneider Electric / Modicon (Modicon Quantum series) - 16I/Os [16DI (16 x digital inputs (115Vac; 16 x 1 input; isolated inputs with no common point))] - Supply voltage 93-138Vac (115Vac nom.) - backplane / rack mounting - with 40-pin screw term. blck. (sold separately) - Rated for +32...+140°F / 0...+60°C ambient
Technical Specifications
| Brand | Schneider Electric |
| Part Number | 140DAI54000 |
| Category | PLCs/Machine Control |
| Subcategory | PLC Module/Rack |
| Type | I/O Modules |
| Module format | Standard |
| Range of product | Modicon Quantum automation platform |
| Product or component type | VAC discrete input modules |
| Software name | Concept ProWORX 32 Unity Pro |
| Discrete input number | 16 |
| Group of channels | 16 |
| Addressing requirement | 1 input word |
| Discrete input voltage | 115 V AC |
| Input current | <= 13.2 mA 47...53 Hz <= 11.1 mA 57...63 Hz |
| Voltage state1 guaranteed | 85...132 V AC at 47...53 Hz 79...132 V AC at 57...63 Hz |
| Voltage state 0 guaranteed | 0...20 V AC at 47...53 Hz 0...20 V AC at 57...63 Hz |
| Input impedance | 14400 Ohm capacitive at 47...53 Hz 12000 Ohm capacitive at 57...63 Hz |
| Network frequency limits | 47...63 Hz |
| Leakage current | <= 2.1 mA |
| Absolute maximum input | 200 V 1 cycle 156 V 10 s 132 V continuous |
| Response time | 7.3...12.3 ms On-Off 4.9...0.75 ms x line cycle Off-On |
| Isolation between channels | 1780 Vrms for 1 minute |
| Isolation between channels and bus | 1780 Vrms for 1 minute |
| Bus current requirement | 180 mA |
| Power dissipation in W | <= 5.5 W |
| Local signalling | 16 LEDs green input status 1 LED red external fault detected (F) 1 LED green bus communication is present (Active) |
Information About 140DAI54000
The Modicon Quantum discrete input module 140 DAI 540 00 is manufactured by Schneider Electric for use on the Modicon Quantum automation platform. The Modicon 140 DAI 540 00 16 x I - 115 V AC module with 16 discrete input channels. The Quantum input module is compatible with Concept, ProWORX 32, and Unity Pro software.
Features of the Modicon Quantum 140 DAI 540 00
The Modicon Quantum 140 DAI 540 00 offers a group of 16 channels with 1 input word addressing. The input current for the Quantum 140 DAI 540 00 module is 11.1 mA 57...63 Hz and 13.2 mA 47...53 Hz. The discrete input voltage for this unit is 115 V AC. The guaranteed state one voltage for the 140 DAI 540 00 is 79...132 V AC 57...63 Hz and 85...132 V AC 47...53 Hz. The zero guarantee voltage state for the Quantum 140 DAI 540 00 is 0...20 V AC, 57...63 Hz, and 0...20 V AC, 47...53 Hz. The input impedance for this module is 12000 Ohm capacitive, 57...63 Hz, and 14400 Ohm capacitive, 47...53 Hz. The network frequency limits are between 47…63 Hz. The max leakage current is 2.1 mA. The absolute maximum input for the Modicon Quantum 140 DAI 540 00 is 132 V continuous, 156 V 10 s, 200 V 1 cycle with a response time of 4.9...0.75 ms x line cycle Off-On and 7.3...12.3 ms On-Off. The isolation between channels is 1780 Vrms for 1 minute and the isolation between channels and bus is 1780 Vrms for 1 minute. The bus current requirement for the Modicon Quantum discrete input module 140 DAI 540 00 is 180 mA. The maximum power dissipation is 5.5 W.
Local signaling for the Modicon Quantum 140 DAI 540 00
The 140 DAI 540 00 Modicon Quantum discrete input module is equipped with LED indicators one through sixteen. The ACTIVE LED indicates green when the unit is ON and bus communication is present. LED indicators one through sixteen indicate green when an indicated point or channel is turned ON.
Presentation
The Modicon Quantum 140 DAI 540 00 displays the color-coded module number and description at the top front of the module. The LED signaling is below the module number on the front panel. Inside a hinged door is the fuse cutout area that houses the field wiring terminal strip. The field wiring terminal strip is a separate item and must be ordered separately. There is spaced inside the hinged door that covers the field wiring strip and fuse cutouts for a customer identification label that you fold and place inside. This label is used to store customer-specific information.
Manufacturer information
Schneider Electric, a global leader in energy management and automation, offers innovative solutions for efficiency and sustainability. With a diverse portfolio spanning power distribution, automation, and renewable energy, Schneider Electric is committed to shaping a more connected and sustainable future.
