140EHC10500 | Schneider Electric | High-speed counter module
- Regular price
- $785.00
- Sale price
- $785.00
- Regular price
-
Couldn't load pickup availability
Do you need more quantity?
Product Description P/N: 140EHC10500
Description
The Modicon Quantum High-Speed Counter Module is designed for precise counting applications in industrial automation. With the capability to handle 8 inputs, this module operates at a high speed with a frequency of 100,000 Hz. Specifically engineered for the Modicon Quantum series, it provides reliable and accurate counting functionality, making it suitable for applications where rapid and precise counting is essential. The module's integration into the Quantum platform ensures seamless compatibility and efficient performance within complex automation systems.
Technical Specifications
Specifications
|
Part # |
140-EHC-105-00 |
|
Manufacturer |
SCHNEIDER ELECTRIC |
|
Brand |
MODICON |
|
Category |
Servo Products |
|
Subcategory |
Servo Drive/Servo Control |
|
Number of inputs |
8 |
|
Addressing requirement |
12 output words <br> 12 input words |
|
Data format |
2147483647 dec 32 bits <br> 65535 dec 16 bits |
|
Counting input voltage |
30 V DC max |
|
Counting input current |
7 mA |
|
Counting input type |
Discrete incremental counter |
|
Counting frequency |
100000 Hz |
|
Duty cycle |
1/1 counter input |
|
Discrete input current |
5 mA |
|
Operating threshold |
15...30 V single ended mode 24 V REF DC at state on <br> 3...5 V single ended mode 24 V REF DC at state off |
|
Discrete output number |
8 |
|
Discrete output type |
Field Effect Transistor (FET) |
|
Discrete output voltage |
0 V switch off DC <br> 20...30 V switch on DC |
|
Load current |
0.21 A |
|
Maximum leakage current |
0.1 mA state off |
|
Maximum voltage drop |
<1.25 V state on |
|
Isolation between channels and bus |
500 Vrms 60 s |
|
Fault type |
Loss of output field power |
|
Output short-circuit protection |
Internal |
|
Power dissipation |
>= 6 W |
|
Bus current requirement |
250 mA |
|
External power requirement |
19.2...30 V |
|
Rack type |
Local <br> Distributed <br> Remote |
|
Local signalling |
For channel status 5 LEDs |
|
Marking |
CE |
|
Current consumption |
<= 1140 mA 24 V DC external power supply |
|
Module format |
Standard |
|
Resistance to electrostatic discharge |
4 kV contact IEC 801-2 <br> 8 kV on air IEC 801-2 |
|
Resistance to electromagnetic fields |
9.14 V/m (10 V/m) 80…1000 MHz IEC 801-3 |
|
Ambient Air Temperature for Operation |
32…140 °F (0…60 °C) |
|
Ambient Air Temperature for Storage |
-40…185 °F (-40…85 °C) |
|
Relative Humidity |
95 % without condensation |
|
Operating altitude |
<= 16404.2 ft (5000 m) |
|
Standards |
UL 508 |
Information About 140EHC10500
The Modicon Quantum high-speed counter module, designated as 8 I, is engineered to operate at a frequency of 100,000 Hz. This module, an integral component of the Modicon Quantum series, specializes in processing high-speed counting tasks within industrial automation systems.
Designed to accommodate eight inputs, the module is equipped to handle high-frequency signals, enabling precise counting operations crucial in industrial settings. Its functionality encompasses the rapid and accurate detection of input signals, ensuring optimal performance in various applications.
As a component of the Modicon Quantum series, renowned for its robustness and reliability, this high-speed counter module upholds stringent quality standards expected in industrial automation environments. Its design prioritizes efficiency and accuracy, catering to the demanding requirements of modern industrial processes.
The high-speed counter module's architecture facilitates seamless integration into existing Modicon Quantum systems, providing compatibility and interoperability with other modules and components within the automation network. This interoperability enhances system flexibility and scalability, allowing for streamlined expansion and customization as per specific application needs.
With a focus on high-speed counting operations, the module ensures precision and consistency in monitoring and processing input signals. Its capability to handle signals at a frequency of 100,000 Hz underscores its suitability for applications demanding rapid and precise data acquisition and processing.
Manufacturer information
Schneider Electric, a global leader in energy management and automation, offers innovative solutions for efficiency and sustainability. With a diverse portfolio spanning power distribution, automation, and renewable energy, Schneider Electric is committed to shaping a more connected and sustainable future.
IQElectro 2 Year Warranty
IQElectro offers a 2-Year Warranty on all our products. This complimentary two-year warranty ensures that every purchase from IQElectro is a secure investment in the future of your company.Warranty Terms and Conditions
IQElectro is not an authorized distributor.
