140EHC20200 | Schneider Electric Modicon Quantum - High-speed Counter Module
- Regular price
- $727.00
- Sale price
- $727.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: 140EHC20200
Description
The Schneider Electric 140EHC20200 is a high-speed counter module designed for the Modicon Quantum automation platform. It supports incremental and quadrature counting with frequencies up to 500 kHz, enabling accurate acquisition of fast pulse signals. This module is suited for industrial applications requiring precise motion, position, or event counting.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Schneider Electric |
| Category | PLCs/Machine Control |
| Part Number | 140EHC20200 |
| Subcategory | PLC Module/Rack |
| Product Platform | Modicon Quantum |
| Product Type | High-speed counter module |
| Number of Channels | 2 |
| Counting Input Type | Incremental or quadrature |
| Maximum Counting Frequency | 500,000 Hz |
| Discrete Input Voltage | < 30 V |
| Input Resistance | 10 kΩ |
| Number of Discrete Outputs | 4 |
| Discrete Output Type | FET |
| Load Current | 0.5 A |
| Maximum Leakage Current | 0.4 mA (off state) |
| Maximum Voltage Drop | < 0.4 V (on state) |
| Isolation | 1780 Vrms for 60 s |
| Bus Current Requirement | 650 mA |
| External Power Supply | 19.2–30 VDC |
| Power Dissipation | 4 + (0.4 × total module load current) |
| Operating Temperature | 0 to 60 °C (32 to 140 °F) |
| Storage Temperature | -40 to 85 °C (-40 to 185 °F) |
| Relative Humidity | Up to 95% non-condensing |
| Standards | UL 508, CE |
Information About 140EHC20200
The 140EHC20200 is part of the Modicon Quantum PLC family and is engineered for high-performance counting and monitoring tasks. It features a standard Quantum module format with electrical isolation between channels and the system bus for reliable operation. The module integrates seamlessly into Quantum racks and supports both incremental and quadrature input modes for flexible application design. It is typically used in automation systems involving encoders, high-speed sensors, and motion-related feedback where accuracy and response time are critical.
Key Features:
- Modicon Quantum compatibility: Designed for Schneider Electric Quantum PLC systems.
- High-speed counting capability: Processes input frequencies up to 500,000 Hz.
- Dual counting channels: Supports two independent high-speed input channels.
- Incremental and quadrature modes: Accommodates common encoder signal types.
- Discrete input support: Accepts input voltages below 30 VDC.
- FET discrete outputs: Provides four fast-switching transistor outputs.
- Electrical isolation: Ensures 1780 Vrms isolation between channels and bus.
- Integrated protection: Includes transorb protection and short-circuit fuse safety.
- Local diagnostics: LED indicators display channel operating status.
- Industrial environmental ratings: Designed for reliable operation in harsh conditions.
The 140EHC20200 delivers the reliability and precision required for high-speed counting, motion monitoring, and real-time feedback in Modicon Quantum industrial automation systems.
