140XTS00200 | Schneider Electric Modicon Quantum, programmable logic controller, screw terminal block, 40 point

Description

The Modicon 140XTS00200 is a CPU module designed for use in the Modicon Quantum automation system, which is manufactured by Schneider Electric. This CPU module provides the processing power and memory needed to run automation programs and control industrial processes.

Technical Specifications

Brand	Schneider Electric
Part Number	140XTS00200
Category	PLCs/Machine Control
Subcategory	PLC Battery/Cable/Accessory
Manufacturer Series	Modicon Quantum
Manufacturer Range	Modicon
Input Voltage	100-120 / 200-500 VAC
Product type	40-way Screw Terminal Block
IP degree of protection	< IP20



Information About 140XTS00200

The Modicon™ Quantum™ PACs provides well balanced CPUs that are able to provide leading performance from boolean to floating point instruction. Quantum PACs is a high level multitasking system with memory capacity up to 7 Mb using PCMCIA extensions. Quantum has plug and play high performance Hot Standby solutions with LCD keypad for local monitoring. Numerous built in ports (USB port, Ethernet TCP/IP port with Web server, Modbus Plus and at least one Modbus serial port) on the front panel. In rack has connectivity to Profibus DP and an embedded Ethernet router. Product range benefits include a large range of processors, Modicon Quantum is ideal for complex processes. The power of its processors results in optimum cycle times, while integrating ever more communication functions, diagnostics, memory flexibility and data storage. For more flexibility chose the best topology, daisy chain loop, ring, star or bus for the design of your Ethernet architecture. Higher availability Hot standby CPUs and daisy chain loop topology improve the availability of your process. In case of cable failure, the recovery time is less than 50 ms for the entire Quantum Ethernet I/O architecture. Increase the availability of your architecture with the CRA and CRP Quantum Ethernet I/O modules (QEIO). Expand your architecture and integrate easily with distributed devices in the same network (such as HMI, variable speed drives, I/O islands, etc.). To facilitate installed base migration the Quantum PAC supports five IEC languages as standard: LD, ST, FBD, SFC, IL and the Modicon LL984 language. This PAC is specially shaped for process control applications with conformal coated modules and has an extensive catalog of partner modules. Safety processors and I/O modules to manage safety integrated systems are available. The Quantum Safety system is now available, certified TUV Rheinland, simple to use and ready to be integrated in your automated system. Quantum PACs are used for process control, infrastructure and safety.

Features
One of the key features of the Modicon 140XTS00200 is its high clock speed of 50 MHz. This fast processing speed allows the CPU module to quickly execute complex control logic, making it ideal for applications that require precise control and high-speed processing. Additionally, the module is equipped with 2 MB of memory, providing ample storage space for automation programs and data.

The Modicon 140XTS00200 supports a range of programming languages, including ladder logic, structured text, and function block diagrams. This flexibility allows engineers and programmers to choose the language that best suits their needs, enabling them to create complex control algorithms and programs that can be easily modified and adapted to changing industrial processes.

Diagnostics
Another important feature of the Modicon 140XTS00200 is its built-in diagnostics. These diagnostics allow for easy troubleshooting and maintenance of the module, helping to minimize downtime and improve overall system reliability. Additionally, the module includes a battery backup, ensuring that automation programs and data are not lost in the event of a power failure.

Application
The Modicon 140XTS00200 is designed to be used in a wide range of industrial applications, including manufacturing, automotive, aerospace, and food processing. It is particularly well-suited to applications that require high-speed processing, complex control logic, and high reliability. Additionally, the module is highly modular, allowing it to be easily integrated into existing control systems and expanded as needed.

Connectivity
In terms of connectivity, the Modicon 140XTS00200 is equipped with a range of communication interfaces, including Ethernet, Modbus, and CANopen. This allows the module to be easily integrated into a range of industrial networks and communication systems, providing real-time data and feedback to operators and engineers.
