1492-IFM20F-F24-2 | Allen-Bradley 20-Point Fusible Digital IFM
- Regular price
- $412.00
- Sale price
- $412.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 1492-IFM20F-F24-2
Description
The Allen-Bradley 1492-IFM20F-F24-2 is a 20-point fusible digital interface module (IFM) engineered for fixed terminal block wiring applications. It integrates fuse protection and visual blown fuse indicators, providing a streamlined and protective I/O solution.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Allen-Bradley |
| Category |
PLCs/Machine Control
|
| Part Number | 1492-IFM20F-F24-2 |
| Subcategory | PLC Module/Rack |
| Terminal Type | Screw Terminals, Sideways Layout |
| Number of Points | 20 |
| Fuse Size | 5 x 20 mm Fuse Clips |
| Blown Fuse Indication | Yes (24 VAC/DC) |
| Amperage | 12 Amp |
| Connector | 20-Pin |
| Standards | C-TICK, CCC, CE, CUL, NRTL, UL |
| Weight | 0.75 lbs |
Information About 1492-IFM20F-F24-2
The 1492-IFM20F-F24-2 is a digital interface module designed for compact wiring of control systems using fixed terminal blocks, offering 20 screw terminals arranged sideways for optimal space utilization. It features integrated 5 x 20 mm fuse clips that protect each output circuit and blown fuse indicators for 24 VAC/DC, enabling immediate visual fault identification. The module supports up to 12 Amps of current and uses a 20-pin connector for quick plug-in installation with compatible cables. It complies with global standards such as CE, UL, CCC, C-TICK, NRTL, and CUL for safe and certified integration in industrial environments.
Key Features:
- 20-Point Terminal Interface: Provides dense and organized terminal connections for digital signals.
- Fuse Protection Per Output: Includes 5 x 20 mm fuse clips with fuse-blown indicators for safety monitoring.
- Sideways Terminal Layout: Optimizes panel space while maintaining easy wiring access.
- High Current Support: Rated for up to 12 Amps to accommodate most industrial loads.
- 24 VAC/DC Indicator Circuits: Enables visual detection of blown fuses across both AC and DC circuits.
- Screw Terminal Connection: Secure and widely compatible termination method.
- Global Standards Compliance: Meets CE, UL, CUL, CCC, C-TICK, and NRTL certifications for international usage.
The 1492-IFM20F-F24-2 ensures safe and compact signal interface with added protection, simplifying maintenance and improving fault visibility in control systems.
