1606-XLP50E | Allen-Bradley AC/DC Compact Power Supply 50W 24-28V 120/230VAC Input

Description

The Allen-Bradley 1606-XLP50E is part of the Essential Switched Mode Power Supply product category. It requires an input power of 100 to 240VAC and 85 to 375 VDC Voltage with Output Voltage of 24 to 28VDC along a 50 W Output Power and Current of 2.1 Amperes at 24.5 VDC and 1.8 Amperes at 28VDC.

Technical Specifications

Information About 1606-XLP50E

The 1606-XLP50PE is an Allen-Bradley power supply that belongs to the bulletin 1606 of Compact Power Supply. This power supply features compatibility with AC and DC voltage supply such as 100 to 240VAC and 85 to 375 VDC. This power supply has a hold-up time of >171 ms at 230V AC and >17 ms at 100V AC. It has a rated efficiency of 88.5% with Mean Time Before Failure (MTBF) of 600, 000 Hours.

Compared to the XLE series power supply, the XLP compact switched mode power supply which features DC-OK output that is used to indicate the operating status of the device via a contact output which may be used to connect to a relay, pilot light or any indicating device. The signal is activated during normal operation and deactivated when errors are detected such as overload, overheating and short circuit.

It also has an integrated Thermal Alarm output that provides warning before and while over temperature is active. Use this output to trigger indicating or sounding devices or interface to an input module of a PLC to monitor the state of the power supply.

The Current monitor output is an integral monitoring circuit to measure the output current that is proportional to the output current of the power supply unit.

This power supply is also equipped with Current Balance capability where load sharing may be implemented when units are connected in parallel.

The 1606-XLP50PE is approved for installation in Hazardous Location applications with Class 1 Division 2 rating.

The 1606-XLP50E power supply is an Allen-Bradley 1606-XLP compact switched-mode power supply that features a rated output wattage of 50 Watts. The compact switched-mode power supply comes with an output current of 2.1 Amps and with minimal heat generation. The power supply has a compact size and is suitable for use in applications with minimal installation space. The 1606-XLP50E power supply features global certifications that indicate that the power supply meets several international safety standards. The 1606-XLP50E power supply is a cost-effective industrial solution that is commonly used for low-power industrial applications. The rated efficiency stands at 80 to 90% and the power supply unit provides an option for screw or spring clamping. The 1606-XLP50E power supply features an ambient operating temperature range of -10 to 70 degrees Celsius. It also comes with an ambient storage temperature range of -40 to 85 degrees Celsius and it weighs only 240 grams. This 1606-XLP switched-mode power supply features status LED indicators that allow for easy monitoring of the drive’s operating status. The LED indicators also provide critical diagnosis status reports. The 1606-XLP50E power supply provides a high level of performance and it is a reliable and compact power supply. This power supply is designed for single-phase application. It has top of the line efficiency and it is a standard Allen-Bradley power supply that is built to save space while minimizing operating expenses. Therefore, it is an ideal industrial power supply that provides unique capabilities at a relatively low cost.
