1734-IK | Allen-Bradley POINT I/O 24V DC Incremental Encoder Module
- Regular price
- $169.00
- Sale price
- $169.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 1734-IK
Description
The Allen-Bradley 1734-IK is a POINT I/O Incremental Encoder Module. It has 1 Counter and an Input Voltage of 15-24 volts DC with an Input Current of 6.1 milliamps at 15 Volts DC. This Incremental Encoder Module has a Key Switch Position of 2.
Technical Specifications
| Brand | Allen-Bradley |
| Series | POINT I/O |
| Part Number | 1734-IK |
| Manufacturer | Rockwell Automation |
| Module Type | Incremental Encoder Module |
| Counter | 1 |
| Input Voltage | 15-24 volts DC |
| Input Current | 6.1 milliamps at 15 Volts DC |
| Input Current | 10.2 mA @ 24V DC |
| Key Switch Position | 2 |
| Enclosure Type Rating | None (Open-Style) |
| Wiring Category | 1 |
| Dimensions | 2.21 x 0.47 x 2.97 in |
Information About 1734-IK
The Allen-Bradley 1734-IK is an incremental encoder counter module. It has 1 input available and it is a group of A/A, B/B, and Z/Z returns. Its key switch position is 2 and its wiring category is 1 on all signal ports. This module can be mounted using a DIN rail mount and is compatible with a 1734-TB, 1734-TBS, 1734-TB3, or a 1734-TB3S wiring base assembly and a 22 to 14 AWG stranded or solid copper wire. Five status indicators are present with this module and these let users see the current state of the module, network, and the A, B, and Z inputs. Both the module and network status indicators are green/red while the A, B, and Z input status indicators are yellow. This module measures 2.21 x 0.47 x 2.97 inches and it weighs 0.08 pounds. It has an open-type enclosure and an external DC power supply is not required.
The 1734-IK can receive feedback from pulse generators and differential or single-ended encoders. It can also process frequencies of up to 1 MHz and return the frequency or count in the form of a 24-bit binary number between 0 and 16,777,215 that is expressed in a 32-bit long word. The 1734-IK module is also compatible with mechanical limit switches. The input voltage of the 1734-IK ranges from 15 to 24 Volts DC and its nominal input is 24 Volts DC. This module has input currents of 6.1 mA at 15 Volts DC and 10.2 mA at 24 Volts DC. During off-state, it has a maximum current that is less than or equal to 0.250 mA and a voltage that is less than or equal to 1.8 Volts DC. When in on-state, it has a current that is equal to or more than 5 mA and a voltage that is less than or equal to 12.5 Volts DC. The maximum POINT bus current of the 1734-IK is 160 mA, the maximum power dissipation is 1.5 W at the rated load, and the maximum thermal dissipation is 5.1 BTU/hour at the rated load. Its operating temperature is -20 to 55 degrees Celsius, its non-operating temperature is -4 to 85 degrees Celsius, and its non-condensing relative humidity is 5 to 95%. It also has an operating vibration of 5 g at 10 to 500 Hertz, an operating shock of 30 g, and a non-operating shock of 50 g.
Manufacturer information
Allen-Bradley, a brand of Rockwell Automation, specializes in manufacturing industrial automation equipment. The product range includes programmable logic controllers (PLCs), motion control systems, safety devices, motor control equipment, automation software, and HMI panels. Allen-Bradley products are known for their reliability and integration with other systems.
