1734-OE4C | Allen-Bradley POINT I/O 24VDC 4-Channel Analog Current Output Module
- Regular price
- $229.00
- Sale price
- $229.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 1734-OE4C
Description
The Allen-Bradley 1734-OE4C is a POINT I/O Analog Output Module. It has Four (4) single-ended, non-isolated, Current output module with Current range of 4 to 20 mA or 0 to 20 mA. It has an integrated Digital to Analog converter with conversion resolution of 16 Bits and absolute accuracy of 0.4% (0.1% if calibrated).
Technical Specifications
| Brand | Allen-Bradley |
| Series | POINT I/O |
| Part Number | 1734-OE4C |
| Manufacturer | Rockwell Automation |
| Module Type | Analog Output Module |
| Outputs | 4 Single Ended |
| Data Format | Signed Integer |
| External DC Supply Current | 220 mA |
| Output Signal Range | 4 to 20 mA, 0 to 20 mA |
| Output Resolution | 16 bits across 0 to 21 mA |
| Conversion Type | Digital-Analog |
| Conversion Rate | 20 microseconds |
| Resolution | 14 bits |
| Dimensions (H x W x L) | 2.21 x 0.47 x 2.97 inches |
| DC Voltage | 10 and 28.8 Volts DC |
| Power Dissipation | 750 Ohms at 1.86 Watts |
Information About 1734-OE4C
The 1734-OE4C is an Allen-Bradley POINT IO module that features Four (4) single-ended, analog output modules which provide 0 to 20 mA or 4-20 mA analog electrical signals. This analog output is used for controlling processes that requires modulating control for increased accuracy, efficiency and flexible control techniques.
The module has a compact form and designed for DIN rail mounting. This module may be used with POINT IO communication adapter such as ProfiBus, ControlNet and Ethernet adapters. The 1734-OE4C memory register is accessible by connecting online to the Programmable Logic Controller’s (PLC) processor. The module’s register is composed of Channel Data and Channel Status. The module’s register size is 4 Bytes.
The 1734-OE4C has Module Status and Network Status indicator light as well as Status indicators for every channel. These indicators are installed on the module’s front panel to indicate the module status, network and channel activity.
Compatible wiring assembly for this analog output module are 1734-TB or 1734-TBS. The 1734-OE8C has a dimension of 56.0 x 12.0 x 75.5 mm (2.21 x 0.47 x 2.97 in.) and weighs 36 g (1.235 oz). Recommended signal wire sizes for this module measures 0.25 to 2.5 mm. sq. or 22 to 14 AWG solid or stranded copper wire rated at 100 ° C (212 ° F), or greater. Recommended maximum insulation size is 1.2 mm (3/64 in.).
The Allen-Bradley 1734-OE4C POINT I/O Analog Output Module comes with Four (4) single-ended, non-isolated, current outputs. It has an output signal range of 0 to 20 mA and a default range of 4 to 20 mA with integral digital to analog converter circuit. It has an output conversion rate of up to 1 ms with an output current accuracy of 0.1% full scale at 77 degrees Fahrenheit (25 degrees Celsius). The module’s current output is 40 ms with output resolution of 16 bits over 0 to 21 mA, 2.5 microA/cnt. The converted data format is in the form of Signed Integer.
The Allen-Bradley 1734-OE4C’s point-bus current reaches up to 75mA at 5 Volts DC. It has a power dissipation of 750 Ohms on each 1.86 Watt output and 0 Ohms on each 2.15 Watt channel. The 1734-OE4C’s maximum thermal dissipation reaches up to 750 Ohms load on each output at 6.34 BTU/hour and a 0 Ohm load on each channel at 7.33 BTU/hour. Compatible terminal base for this module are 1734/TB/TBS/TOPS/TOP and installed with the keyswitch set to position 4. The module’s nominal voltage supply is 24 Volts DC with acceptable range of 10.0 to 28.8 VDC. It has an isolation voltage of 50 Volts continuous with a basic insulation type, tested to withstand 1500 Volts AC for 60 seconds.
The 1734-OE4C’s operating temperature range is -4 to 131 degrees Fahrenheit and its storage temperature range is -40 to 185 degrees Fahrenheit. It has an operating shock of 30 G and a non-operating shock of 50 G. Its relative humidity reaches up to 95% non-condensing with operating vibration of 5 G at 10 to 500 Hertz. This analog output module has an output resolution of 16 bits across 0 to 21 mA.
Manufacturer information
Allen-Bradley, a brand of Rockwell Automation, specializes in manufacturing industrial automation equipment. The product range includes programmable logic controllers (PLCs), motion control systems, safety devices, motor control equipment, automation software, and HMI panels. Allen-Bradley products are known for their reliability and integration with other systems.
Description
The Allen-Bradley 1734-OE4C is a POINT I/O Analog Output Module. It has Four (4) single-ended, non-isolated, Current output module with Current range of 4 to 20 mA or 0 to 20 mA. It has an integrated Digital to Analog converter with conversion resolution of 16 Bits and absolute accuracy of 0.4% (0.1% if calibrated).
Technical Specifications
| Brand | Allen-Bradley |
| Series | POINT I/O |
| Part Number | 1734-OE4C |
| Manufacturer | Rockwell Automation |
| Module Type | Analog Output Module |
| Outputs | 4 Single Ended |
| Data Format | Signed Integer |
| External DC Supply Current | 220 mA |
| Output Signal Range | 4 to 20 mA, 0 to 20 mA |
| Output Resolution | 16 bits across 0 to 21 mA |
| Conversion Type | Digital-Analog |
| Conversion Rate | 20 microseconds |
| Resolution | 14 bits |
| Dimensions (H x W x L) | 2.21 x 0.47 x 2.97 inches |
| DC Voltage | 10 and 28.8 Volts DC |
| Power Dissipation | 750 Ohms at 1.86 Watts |
Information About 1734-OE4C
The 1734-OE4C is an Allen-Bradley POINT IO module that features Four (4) single-ended, analog output modules which provide 0 to 20 mA or 4-20 mA analog electrical signals. This analog output is used for controlling processes that requires modulating control for increased accuracy, efficiency and flexible control techniques.
The module has a compact form and designed for DIN rail mounting. This module may be used with POINT IO communication adapter such as ProfiBus, ControlNet and Ethernet adapters. The 1734-OE4C memory register is accessible by connecting online to the Programmable Logic Controller’s (PLC) processor. The module’s register is composed of Channel Data and Channel Status. The module’s register size is 4 Bytes.
The 1734-OE4C has Module Status and Network Status indicator light as well as Status indicators for every channel. These indicators are installed on the module’s front panel to indicate the module status, network and channel activity.
Compatible wiring assembly for this analog output module are 1734-TB or 1734-TBS. The 1734-OE8C has a dimension of 56.0 x 12.0 x 75.5 mm (2.21 x 0.47 x 2.97 in.) and weighs 36 g (1.235 oz). Recommended signal wire sizes for this module measures 0.25 to 2.5 mm. sq. or 22 to 14 AWG solid or stranded copper wire rated at 100 ° C (212 ° F), or greater. Recommended maximum insulation size is 1.2 mm (3/64 in.).
The Allen-Bradley 1734-OE4C POINT I/O Analog Output Module comes with Four (4) single-ended, non-isolated, current outputs. It has an output signal range of 0 to 20 mA and a default range of 4 to 20 mA with integral digital to analog converter circuit. It has an output conversion rate of up to 1 ms with an output current accuracy of 0.1% full scale at 77 degrees Fahrenheit (25 degrees Celsius). The module’s current output is 40 ms with output resolution of 16 bits over 0 to 21 mA, 2.5 microA/cnt. The converted data format is in the form of Signed Integer.
The Allen-Bradley 1734-OE4C’s point-bus current reaches up to 75mA at 5 Volts DC. It has a power dissipation of 750 Ohms on each 1.86 Watt output and 0 Ohms on each 2.15 Watt channel. The 1734-OE4C’s maximum thermal dissipation reaches up to 750 Ohms load on each output at 6.34 BTU/hour and a 0 Ohm load on each channel at 7.33 BTU/hour. Compatible terminal base for this module are 1734/TB/TBS/TOPS/TOP and installed with the keyswitch set to position 4. The module’s nominal voltage supply is 24 Volts DC with acceptable range of 10.0 to 28.8 VDC. It has an isolation voltage of 50 Volts continuous with a basic insulation type, tested to withstand 1500 Volts AC for 60 seconds.
The 1734-OE4C’s operating temperature range is -4 to 131 degrees Fahrenheit and its storage temperature range is -40 to 185 degrees Fahrenheit. It has an operating shock of 30 G and a non-operating shock of 50 G. Its relative humidity reaches up to 95% non-condensing with operating vibration of 5 G at 10 to 500 Hertz. This analog output module has an output resolution of 16 bits across 0 to 21 mA.
Manufacturer information
Allen-Bradley, a brand of Rockwell Automation, specializes in manufacturing industrial automation equipment. The product range includes programmable logic controllers (PLCs), motion control systems, safety devices, motor control equipment, automation software, and HMI panels. Allen-Bradley products are known for their reliability and integration with other systems.
