1746-FIO4V | Allen Bradley SLC 500 Analog Combination Module
- Regular price
- $887.00
- Sale price
- $887.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 1746-FIO4V
Description
The Allen-Bradley 1746-FIO4V SLC 500 Fast Analog Combination Module is a high-performance I/O module designed for fast analog input and output operations. With two fast analog input channels and two voltage output channels, it offers exceptional precision and response times in industrial automation systems.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Allen Bradley |
| Category | PLCs and Accessories |
| Part Number |
1746-FIO4V |
| Subcategory | PLC Expansion Modules |
| Series | SLC 500 |
| Inputs | 2 |
| Module Type | Analog Combination Module |
| Outputs | 2 |
| Backplane Current (5 Volts) | 55 milliamps |
| Backplane Current (24 Volts) | 150 milliamps |
| Input Signal Range | 0…20 mA (nom); 0…30 mA (max) |
| Output Signal Range | –10 … 10V – 1 LSB (normal) |
| Update Time | 512 microseconds |
| Resolution | 12 bits in, 14 bits out |
Information About 1746-FIO4V
The 1746-FIO4V module is a fast analog combination module from Allen-Bradley, specifically designed for the SLC 500 controller platform. It provides two selectable differential analog input channels that support both voltage and current inputs and two analog voltage output channels. This module features a 12-bit resolution for input and 14-bit resolution for output, ensuring high accuracy. Its input channels have a range of 0-20 mA and a maximum input voltage of ±7.5V DC or 7.5V AC RMS, while the output channels deliver a voltage range of -10V to +10V DC. Designed for robust performance, the module has a fast response time, low update time, and a bandwidth of 7 KHz, ensuring quick and accurate data processing.
Key Features:
- Input Channels: Two fast analog input channels, configurable for voltage or current input.
- Output Channels: Two voltage output channels with a range of -10V to +10V DC.
- High Resolution: 12-bit input resolution and 14-bit output resolution for enhanced accuracy.
- Fast Response Time: 100 milliseconds for input and 2.5 milliseconds for output at 95% step response.
- Update Time: 512 milliseconds for quick data updates.
- Bandwidth: 7 KHz for high-speed signal processing.
- Enclosure: Open-type chassis mount with field wiring to a backplane isolation of 500V DC.
- LED Status Indicator: Visual feedback for monitoring operational status.
The 1746-FIO4V module is a reliable and efficient solution for fast analog I/O operations, ensuring seamless integration with the SLC 500 controller. Its high-speed performance and precise analog processing make it an ideal choice for demanding industrial applications.
