Product Description P/N: 1746SC-INO4I
Description
The Allen-Bradley 1746SC-INO4I is an Analog Output Module for SLC 500 systems, offering 4 isolated output channels with configurable voltage or current outputs. It ensures precise signal control for industrial automation applications.
Technical Specifications
Condition | New/Never Used Surplus |
Brand | Allen Bradley |
Category | PLCs/Machine Control |
Part Number | 1746SC-INO4I |
Subcategory |
PLC Module/Rack
|
Weight | 0.57 lbs |
Channels | 4 |
No. of Outputs | Four (4), Isolated |
Output Current range | 0-20 mA, 0-21 mA, 4-20 mA |
Input Current | 0-20 mA |
Resolution | 16 bits |
Step Response | 1 ms to 95% of full scale |
Full Scale Output | 21 mA |
Output Impedance | >1 Mohm |
Maximum Resistance | 500 Mohm |
Ambient Operating Temperature | 0 to 60 degrees Celsius |
Backplane Current Required | 120 mA at 5 V; 250 mA at 24 V |
Thermal Dissipation | 5 Watts, maximum |
Information About 1746SC-INO4I
The Allen-Bradley 1746SC-INO4I is an Analog Output Module designed for the SLC 500 series, offering precise signal control for a variety of industrial automation applications. It provides 4 isolated output channels that can be configured for either voltage or current output.
Key Features:
- Model: 1746SC-INO4I
- Type: Analog Output Module
- Manufacturer: Allen-Bradley
- Channels: 4 isolated analog output channels
- Output Type:
- Voltage: 0-10V DC, ±10V DC
- Current: 4-20mA, 0-20mA
- Resolution: 12-bit (1 part in 4096)
- Output Accuracy: ±0.1% of full scale
- Isolation: Provides isolation between the controller and field devices for better noise immunity
- Communication: Interfaces with SLC 500 controllers over the backplane
- Backplane Current: 100mA at 5V DC
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Certifications: UL, CE, and CSA certifications for industrial safety standards
- Indicators: LEDs for status and diagnostics of each output channel
- Mounting: Designed to mount directly to the SLC 500 I/O chassis
Applications:
- Process Control: Ideal for controlling valves, actuators, and other devices requiring precise analog outputs
- Industrial Automation: Provides reliable voltage or current signals to external equipment in automated systems
- Measurement Systems: Suitable for environments requiring accurate, real-time analog signal generation
- Remote Control: Used in remote control applications where analog signals need to be transmitted from a central controller
The Allen-Bradley 1746SC-INO4I Analog Output Module provides high-precision control and isolation, offering an efficient solution for analog signal management in SLC 500-based automation systems.
