Part #: 1747-AIC Manufactured by: Allen-Bradley
Regular price
$392.00
Sale price
$392.00
Regular price
18 in Stock
Condition: New-Surplus Original Box
Shipping calculated at checkout.
Product Overview
The Allen-Bradley 1747-AIC is a SLC 500 Isolated Link Coupler. This Isolated Link Coupler has a Shielded Twisted-Pair Comm...  Read more
We accept:
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Venmo
  • Visa
warranty
IQElectro 2-Year Warranty
Warranty for Product #: 1747-AIC
IQElectro offers a free 2-year warranty on all products. You can trust that every purchase is a reliable investment in the future of your company. Warranty Terms
2-3 Day Free Shipping
Packed Ready to Ship
24/7 Expert Support
Return within 30-Days
IQElectro LLC BBB Business Review
IQElectro is Not an authorized distributor for Allen-Bradley
Original Manufacturer's Warranty Not Covered, This Product is SURPLUS.

Product Description P/N: 1747-AIC

Description / Specifications

Description

The Allen-Bradley 1747-AIC is a SLC 500 Isolated Link Coupler. This Isolated Link Coupler is a panel mounted device that is compatible for use with an SLC Fixed and modular style hardware. It has communication ports to allow a connected SLC controller to connect to a programming workstation and to a DH485 network.



Technical Specifications



Brand Allen-Bradley
Series SLC 500
Part Number 1747-AIC
Manufacturer Rockwell Automation
Module Type Isolated Link Coupler
Communication Interface Shielded Twisted-Pair
Current Load (24 Volt DC) 0.085 Amps
External Power 24VDC
Location Slot 0
Rated Current 190 mA
Backplane Current (5 Volts) 470 milliamps
Thermal Dissipation 2.49 Watts
Communication terminals DH485, Peripheral and CPU
Isolation Voltage 50 Volts Continuous
LED Indicator Power LED
Enclosure Open
Dimensions 5.72 x 1.37 x 5.15 inches
Installation Panel Mounted
USB communication peripherals 1747-UIC; 1747-C13
Operating Temperature 0 to 60 degrees Celsius
RS232communication Peripherals 1747-PIC; 1747-C10
PCMCIA or 1784-PCMK communication peripherals 1784-PCM4





Information About 1747-AIC

The Allen-Bradley 1747-AIC is an isolated link coupler. The panel-mountable coupler conforms to the NEMA standard ICS 2-230, IEC1000-4-2, EN50081-2 Class A, and the IEC1000-4-3 regulations and standards. In addition, this device is CSA certified. The dimensions of the coupler are 1.5 x 6.8 x 6.5 inches with current load of this isolated link coupler is 0.085 Amps at 24 Volts DC. Moreover, the Allen-Bradley 1747-AIC offers an advanced interface converter with a shielded twisted-pair communication interface. This interface helps with communication between several network devices in the SLC 500 family such as the SLC 5/02, SLC 5/01, and the SLC 5/03 processors and the DH-485 link.

Note that connecting more than 2 SLC500 processors with a DH-485 link requires 1 isolated coupler on the 1747-AIC drive. Also, 1 link coupler should be connected at each end of the link if a computer or DTAM is linked at a distance greater than 20 feet or 6.09 meters. To connect with the processor, an Allen-Bradley 1747-C11 cable is provided with the coupler. To connect to the DH-485 communication cable, the coupler offers a 6-position removable terminal block. The communication cable is 1219 meters or 4000 feet in length. The backplane current of the 1747-AIC is 0 mA at 5 Volts and 85 mA at 24 Volts. The thermal dissipation is 2 W minimum and 2 W maximum, respectively and the relative humidity range of the 1747-AIC drive is from 5 to 95% without condensation. The isolated coupler comes with 1 G operating vibration at 5 to 2000 Hertz operating vibration and 2.5 G non-operating vibration at 5 to 2000 Hertz. For a 24 Volts DC power source, the coupler requires 20.4 to 28.8 Volts DC.

The 1747- Advanced Interface Converter (AIC) Link coupler which allows an SLC 500 fixed style or modular style processor to be communicated or multiplexed with a programming workstation, DH485 network and compatible devices.

This Link Coupler is a panel mounted device. It has a DH485 communication terminal, Peripheral connection and a CPU port. It also has a LED indicator to provide power supply feedback.

If planning to connect an SLC processor, each processor must be installed with One (1) Link coupler. This enables the connected processor to be connected to a DH485 network while allowing simultaneous communication with a programming workstation through one of the integrated port.

There are a variety of ways to connect a programming workstation such as a personal computer to the link coupler. The computer may use the integrated USB port, combined with a 1747-UIC converter and 1747-C13 cable. Through the computer’s RS232 serial communication port, 1747-PIC may be used combined with 1747-C10 communication cable. For a PCMCIA slot or a computer with 1784-PMCK, 1784.PMC4 communication cable is required. All these communication cables connect to the link’ coupler’s single peripheral terminal.

To connect the controller to a DH485 communication network, Belden #3106A or #9462 shielded twisted pair cable is required. DH485 is designed for daisy chain topology with a maximum length of cable segments of 1219 m or 4000 ft.

If connected to an SLC 500 processor, the link coupler is powered via the communication port; otherwise, an external 24VDC power supply is required to power the link coupler device.



Manufacturer information

Allen-Bradley, a brand of Rockwell Automation, specializes in manufacturing industrial automation equipment. The product range includes programmable logic controllers (PLCs), motion control systems, safety devices, motor control equipment, automation software, and HMI panels. Allen-Bradley products are known for their reliability and integration with other systems.

IQElectro is not an authorized distributor.
QElectro LLC (IQElectro) is NOT an Authorized Distributor or in any way affiliated with Rockwell Automation, Siemens, or any other Manufacturers. IQElectro is NOT an Authorized Dealer of this product. The product may be of older version, date codes, or design than that available from authorized dealers. As IQElectro is not an authorized dealer of this product, the Original Manufacturer's Warranty and Support DO NOT apply. IQElectro sells SURPLUS only and DOES NOT SELL SOFTWARE or FIRMWARE licenses For more detailed information, please refer to the full version of our disclaimer policy Disclaimer Policy.
