1756-ENBT/A | Allen Bradley ControlLogix EtherNet/IP Bridge
- Regular price
- $397.00
- Sale price
- $397.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 1756-ENBT/A
Description
The Allen-Bradley 1756-ENBT/A is an Ethernet/IP communication bridge module for the ControlLogix platform. It provides robust and high-speed network integration, supporting up to 64 TCP and 128 CIP connections. With a communication rate of 10/100 Mbps and a single-slot chassis design, the 1756-ENBT enables real-time data exchange, diagnostics access, and distributed I/O control through a single, simplified Ethernet network.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Allen Bradley |
| Category |
PLCs/Machine Control
|
| Part Number | 1756-ENBT/A |
| Subcategory | PLC Module/Rack |
| Series | ControlLogix |
| Module Type | Ethernet Communication Module |
| TCP Connections | Up to 64 |
| CIP Connections | Up to 128 |
| Communication Speed | 10/100 Mbps (auto-negotiation) |
| Integrated Ports | 1 x RJ45, 1 x USB 1.1 |
| Packet Throughput | 5000 I/O, 900 HMI/MSG packets/sec |
| Power Dissipation | 3.7 Watts |
| Thermal Dissipation | 12.6 BTU/hr |
| Current Draw (5.1V DC) | 700 mA |
| Current Draw (24V DC) | 3 mA |
| Insulation Voltage | 30V Continuous |
| Slot Width | 1 Slot |
| Mounting | Any slot in ControlLogix chassis |
| Operating Temperature Range | 0 to 60 °C (32 to 140 °F) |
| Enclosure Type | Open |
| USB Version | USB 1.1 |
| Compatibility |
Backward compatible with legacy systems |
| Weight | 1.00 lbs |
Information About 1756-ENBT/A
The 1756-ENBT/A is a first-generation ControlLogix Ethernet/IP bridge module developed by Allen-Bradley, part of Rockwell Automation’s ControlLogix series. It allows industrial controllers to communicate across Ethernet networks using the Common Industrial Protocol (CIP), and supports up to 5000 I/O packets per second with auto-negotiation functionality. It is web-enabled, offering diagnostics and configuration access via a standard browser. The 1756-ENBT/A can function both in local and remote I/O chassis and is compatible with older system versions, enhancing network flexibility.
Key Features:
- Ethernet/IP Protocol Support: Enables high-speed industrial networking over standard Ethernet infrastructure.
- 64 TCP Connections: Supports simultaneous communication with multiple devices without multiplexer requirements.
- 128 CIP Connections: Allows extensive I/O control and real-time data exchange over CIP.
- Web-Enabled Diagnostics: Access module status, IP setup, collision histograms, and network health via browser.
- High Packet Throughput: Handles up to 5000 I/O and 900 HMI/MSG packets per second.
- Auto-Negotiating Speed: Communicates at 10 or 100 Mbps with automatic speed and duplex detection.
- Chassis Versatility: Installs in any slot of a ControlLogix chassis and supports remote I/O operation.
- Single-Slot Design: Occupies minimal space in the control cabinet, enhancing scalability.
- Integrated RJ45 and USB Ports: Offers standard Ethernet and configuration access.
- Backward Compatibility: Seamlessly integrates into legacy ControlLogix systems.
The 1756-ENBT/A delivers the reliability and precision required for high-performance industrial communication.
