1756-L1M1 | Allen-Bradley ControlLogix Logix5550 Processor, 512KB Memory
- Regular price
- $497.00
- Sale price
- $497.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 1756-L1M1
Description
The Allen-Bradley 1756-L1M1 is a ControlLogix 5550 controller. A 500 Kbyte data and logic memory and a 150 Kbyte I/O memory are available for this particular module. It does not have a nonvolatile memory. This controller can be installed in any available slot of the chassis. It also has an open-style enclosure type rating.
Technical Specifications
| Manufacturer | Rockwell Automation |
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 1756-L1M1 |
| Series | ControlLogix |
| Module Type | Processor Module |
| Expansion Memory | 512 KB |
| Enclosure | Open |
| Isolation Voltage | 30 Volts Continuous |
| Operating Temperature | 32-140 Fahrenheit (0-60 Celsius) |
| Minimum Operating Current | 2 milliamps at 10 Volts DC |
| Maximum Operating Current | 3.5 milliamps at 30 Volts DC |
| Maximum Input Current, Off-State | 1.5 milliamps |
| Power Dissipation (Max) | 4.1 Watts at 60 degrees Celsius |
| Backplane Current at 5 Volts | 120 milliamps |
| Backplane Current at 24 Volts | 2 milliamps |
| Removeable Terminal Block(s) | 1756-TBCH, 1756-TBS6H |
Information About 1756-L1M1
The Allen Bradley 1756-L1M1 controller has a battery that can be replaced. The 1756-BA1, which is a 0.59g lithium battery, is the only compatible replacement battery for it. Also, only the 1756-CP3 serial cable category 3 is the compatible programming cable for the 1756-L1M1.
It has a noncondensing relative humidity of 5% to 95%. The operating temperature range of the 1756-L1M1 controller is from 0 to 60 Degrees Celsius, while the storage temperature range is from -40 to 85 Degrees Celsius.
The 1756-L1M1 controller has a backplane current of 950 mA at 5.1V and 20 mA at 24V, and a module power of 5.33 W. It has an average power dissipation of 4.6 W and an average thermal dissipation of 15.6 BTU/hr.
Vibration of the 1756-L1M1 controller ranges from 10 to 500 Hz with a 2.0 G maximum peak acceleration. It has an operating shock of 30 G peak for 11 ms. Storage shock of the 1756-L1M1 is 50 G peak for 11 ms. It also has an isolation voltage of 30V and has been tested to withstand 500 Volts for 60 seconds.
It has an ESD immunity of 6 kV contact discharges and 8 kV air discharges. Its radiated RF immunity is 10V/m with 1 kHz sine-wave 80%AM from 30 MHz to 1000 MHz and 10V/m with 200 Hz 50% Pulse 100% AM at 900 MHz. The controller also has an EFT/B immunity of +/-4 kV at 2.5 kHz on power ports and +/-2 kV at 5 Hz on communication ports. It has a conducted RF immunity of 10Vrms with 1 kHz sine-wave 80%AM from 150 kHz to 80 MHz.
Manufacturer information
Allen-Bradley, a brand of Rockwell Automation, specializes in manufacturing industrial automation equipment. The product range includes programmable logic controllers (PLCs), motion control systems, safety devices, motor control equipment, automation software, and HMI panels. Allen-Bradley products are known for their reliability and integration with other systems.
