1766-L32BXB | Allen-Bradley MicroLogix 1400 PLC, 24V DC Power
- Regular price
- $337.00
- Sale price
- $337.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 1766-L32BXB
Description
The Allen-Bradley 1766-L32BXB is a MicroLogix 1400 programmable logic controller (PLC) designed for small to mid-sized automation applications. It provides 32 digital I/O points, combining DC inputs and transistor outputs for high-speed switching.
Technical Specifications
| Brand | Allen-Bradley |
| Series | MicroLogix 1400 |
| Part Number | 1766-L32BXB |
| Manufacturer | Rockwell Automation |
| Product Family | MicroLogix |
| Module Type | Controller |
| Product Type | MicroLogix 1400 Controller |
| Inputs | (12) Digital Fast 24V DC, (8) Digital Normal 24V DC, (2) Analog |
| Outputs | (6) Relay, (3) Fast 24V DC, (3) Normal 24V DC |
| Number of I/O | 32 points |
| Operating Power | 24V DC |
| Number of Discrete Inputs | Twelve (12) Fast 24VDC; Eight (8) Normal 24VDC |
| Channel Count | (20) IP, (12) OP |
| Analog Input Signal Range | None |
| Number of Discrete Outputs | Six (6) Relay; Three (3) Fast DC; Three (3) Normal DC |
| Memory | 20 KB |
| Feature | Built-in RTC |
| Communication | Ethernet/IP |
| Operating Frequency | 47-63 Hz |
| Power Consumption | 50W; 7.5W (with no 1762 expansion I/O) |
| Power supply inrush current | 24V DC: 15 A for 20 ms |
| Communication port | 1 RS232 / RS485; 1 Ethernet; 1 RS232 |
| Supported Protocols | Serial: DF1, ASCII, MODBUS RTU, DNP3, DH485 Ethernet: Ethernet I/P, DNP3, MODBUS TCP/IP |
| Dimensions | 90 x 180 x 87 mm (3.5 x 7.087 x 3.43 in) |
| Mounting | Panel Mounting / DIN Rail |
Information About 1766-L32BXB
The 1766-L32BXB is part of the Allen-Bradley MicroLogix 1400 family, developed to deliver enhanced features in a compact PLC platform. It operates on a 24V DC power supply and includes 20 digital inputs and 12 transistor (sourcing) outputs, supporting fast response for motion-related or high-speed control applications. The controller is expandable up to 256 I/O points using 1762 MicroLogix expansion modules. Communication options include built-in Ethernet, RS-232, and RS-485 ports, supporting protocols such as Modbus TCP/IP and DNP3. It also features an integrated LCD display for local monitoring, configuration, and diagnostics, along with a real-time clock for scheduling and time-based operations. Programming is performed with RSLogix 500 software, providing a familiar environment for users of other Allen-Bradley PLCs.
Key Features:
- Design: Compact MicroLogix 1400 PLC with transistor outputs for high-speed control.
- I/O Capacity: 32 digital I/O (20 inputs, 12 sourcing transistor outputs).
- Expandability: Supports up to 256 I/O points with 1762 expansion modules.
- Power Supply: Operates on 24V DC input power.
- Connectivity: Built-in Ethernet, RS-232, and RS-485 ports with Modbus TCP/IP and DNP3 support.
- User Interface: Integrated LCD with keypad for monitoring and configuration.
- Functionality: Real-time clock supports scheduling and time-stamped operations.
- Application Range: Ideal for packaging, HVAC, conveyors, and compact automation systems.
The 1766-L32BXB delivers the speed, flexibility, and connectivity required for efficient control in small to mid-sized industrial automation applications.
