1766-L32BXBA | Allen-Bradley MicroLogix 1400 PLC, 24V DC Power
- Regular price
- $499.00
- Sale price
- $499.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 1766-L32BXBA
Description
The Allen-Bradley 5069-OF8 is an analog output module designed for Compact 5000 I/O systems. It provides eight high-resolution output channels for precise voltage or current signal generation.
Technical Specifications
| Condition | New / Never Used Surplus |
| Brand | Allen-Bradley |
| Series | MicroLogix 1400 |
| Part Number | 1766-L32BXBA |
| Manufacturer | Rockwell Automation |
| Product Family | MicroLogix |
| Supported Protocols | Serial: DF1, ASCII, MODBUS RTU, DNP3, DH485 Ethernet: Ethernet I/P, DNP3, MODBUS TCP/IP |
| Communication port | One (1) isolated RS232 / RS485 combo port; One (1) non-isolated RS232 communication port; One (1) Ethernet communication port. |
| Power supply inrush current | 24V DC |
| Power Consumption | 24V DC: 15 A for 20 ms |
| Operating Frequency | 47-63 Hz |
| Analog Input Voltage range | 0…10.0VDC - 1 LSB |
| No. of Analog inputs | Two (2) Voltage |
| Relay Output operating range | 5 - 125V DC / 5 - 264V AC |
| Number of outputs | Six (6) Relay; Three (3) Fast DC; Three (3) Normal DC |
| Input Operating Range | 0-24VDC |
| Number of Inputs | Twelve (12) Fast 24VDC; Eight (8) Normal 24VDC |
| Number of I/O | 32 |
| Product Type | MicroLogix 1400 Controller |
| Module Type | Controller |
| Inputs | (12) Digital Fast 24V DC, (8) Digital 24V DC, (4) Analog |
| Outputs | (6) Relay, (3) Fast 24V DC, (3) Normal 24V DC, (2) Analog |
| Operating Power | 24V DC |
| Channel Count | (20) IP, (12) OP |
| Memory | 20 KB |
Information About 1766-L32BXBA
The 5069-OF8 is part of the Allen-Bradley Compact 5000 I/O 5069 series, developed for use with CompactLogix 5380, ControlLogix 5580, and GuardLogix controllers. This module provides eight individually configurable analog outputs, supporting ranges such as 0–20 mA, 4–20 mA, 0–10V, and ±10V. It delivers 16-bit resolution for high accuracy in controlling actuators, drives, and proportional valves. The module integrates with the 5069 backplane for high-speed communication and includes per-channel diagnostics and status LEDs for monitoring and troubleshooting. DIN rail–mounted and compact, the 5069-OF8 is well-suited for scalable distributed architectures while maintaining precise signal quality.
Key Features:
- Design: Analog output module for 5069 Compact I/O systems.
- Channels: Provides 8 individually configurable output channels.
- Signal Ranges: Supports voltage and current outputs (0–20 mA, 4–20 mA, 0–10V, ±10V).
- Resolution: 16-bit conversion ensures high precision control.
- Compatibility: Integrates with CompactLogix 5380, ControlLogix 5580, and GuardLogix controllers.
- Diagnostics: Built-in per-channel status and fault monitoring.
- Installation: DIN rail–mounted with modular expansion capability.
- Application Range: Suitable for process control, proportional valve actuation, and industrial automation.
The 5069-OF8 delivers the precision, flexibility, and reliability required for advanced analog output control in modern automation systems.
