1769-L33ERM | Allen-Bradley CompactLogix 5370 Ethernet Controller, 2MB Memory
- Regular price
- $2,046.00
- Sale price
- $2,046.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 1769-L33ERM
Description
The Allen-Bradley 1769-L33ERM is a CompactLogix 5370 L3 controller designed for small to mid-size automation applications. It offers 2 MB of user memory, dual embedded EtherNet/IP ports, and USB connectivity. With integrated motion support for up to 8 axes and compatibility with distributed Compact I/O, it provides a flexible and scalable control solution for OEMs and process industries.
Technical Specifications
| Brand | Allen-Bradley |
| Series | A and B |
| Part Number | 1769-L33ERM |
| Manufacturer | Rockwell Automation |
| No. of I/O banks | 3 |
| Local I/O modules | 16 I/O modules |
| Ethernet/IP Nodes | 32 Ethernet/IP Nodes |
| Non-volatile memory | 1GB via 1784-SD1 (ships with the controller) |
| No. of tasks | 32 |
| Communication Ports | 1 Type B 2.0 Full-Speed USB and 2 Ethernet/IP Ports |
| Communication rate, Ethernet | 10 Mbps / 100 Mbps |
| Communication rate, USB | 12 Mbps |
| Integrated Motion | Yes |
| Motion Axes, maximum | 8 Motion Axes |
| Module Type | Compact Controller |
| Programming Languages | Sequential Function Chart, Function Block Diagram, Structured Text, and Ladder Diagram |
| Product Line | CompactLogix |
| Communication | Ethernet |
| Memory | 2 MB |
| Shipping Dimensions | 8 x 8 x 5 inches |
| Operating Shock | 20 to 30 G |
| Wire Type | Copper-90 degrees Celsius |
| Wire Size (Solid) | 22-14 AWG |
| Wire Size (Stranded) | 22-16 AWG |
| Operating Temperature | 0 to 60 degrees Celsius |
Information About 1769-L33ERM
The 1769-L33ERM belongs to the CompactLogix 5370 family, combining high-performance processing with a compact form factor. It supports up to 16 local Compact I/O modules with expansion into 3 remote banks, giving flexibility in system design. The controller includes 2 MB of user RAM and ships with a 1 GB non-volatile SD card (expandable to 2 GB). Dual Ethernet ports provide 10/100 Mbps communication with support for Linear, Star, and Device Level Ring (DLR) topologies, connecting up to 16 EtherNet/IP nodes. Integrated motion over EtherNet/IP allows configuration of up to 8 axes, making it suitable for coordinated motion control tasks. Programming languages include Ladder Diagram, Structured Text, Function Block Diagram, and Sequential Function Chart. The controller supports up to 32 tasks and 100 programs per task. It operates in ambient conditions up to 60 °C with built-in diagnostics, energy storage (eliminating battery needs), and robust shock and vibration tolerance for industrial environments.
Key Features:
- Design: CompactLogix 5370 L3 controller with scalable architecture.
- User Memory: 2 MB RAM; ships with 1 GB SD card (expandable to 2 GB).
- I/O Support: Up to 16 Compact I/O modules and 3 expansion banks.
- Ethernet Ports: Dual 10/100 Mbps ports with Linear, Star, and DLR topologies.
- USB Port: For local programming and firmware updates.
- Integrated Motion: Supports up to 8 EtherNet/IP motion axes.
- Performance: Handles 32 tasks with up to 100 programs per task.
- Safety: Integrated safety functionality, supporting SIL 3 and PLe CAT 4 applications.
- Diagnostics: Built-in status indicators and energy storage for battery-free operation.
- Environmental Ratings: Operates 0…60 °C, humidity 5–95% non-condensing, shock/vibration rated for industrial use.
The 1769-L33ERM delivers powerful motion, safety, and communication capabilities in a compact package, making it a versatile controller for demanding mid-range automation systems.
