1771-P4R | Allen Bradley PLC-5 Redundant Power Supply
- Regular price
- $392.00
- Sale price
- $392.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 1771-P4R
Description
The Allen-Bradley 1771-P4R is a redundant power supply module designed for the PLC-5 system. It operates with an input voltage range of 97-132V AC at 47-63 Hz and provides a 5V DC output with an 8A current capacity to the backplane.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Allen Bradley |
| Category | PLCs and Accessories |
| Part Number |
1771-P4R |
| Subcategory | PLC Expansion Modules |
| Input Voltage Range | 97-132 VAC |
| Module Type | Redundant Power Supply |
| Input voltage frequency | 47-63 Hz |
| Output voltage | 5 VDC |
| Maximum output current at 60o C using N+1 Redundancy | 8A (2 unit system); 14A (3 unit system); 20A (4 unit system) |
| Alarm Relay Rating | 250 VAC |
| Operating temperature | 32 to 131oF |
| Relative Humidity | 5-95 % |
| Nom Input Voltage | 120 Volts AC |
Information About 1771-P4R
The 1771-P4R redundant power supply module enhances system reliability in PLC-5 installations by providing backup power capabilities. It supports N+1 redundancy configurations, enabling continuous operation even in the event of a power module failure. With a maximum output current of 8A in a single module system, it can scale to 14A or 20A in 3- or 4-unit configurations, respectively, at 60°C. The module is equipped with an alarm relay rated for 250VAC to signal system issues promptly. Its robust design ensures dependable power delivery for demanding industrial automation environments.
Key Features:
- Input Voltage Range: Operates at 97-132V AC with a frequency range of 47-63 Hz.
- Output Voltage: Delivers 5V DC to the backplane.
- Output Current: Provides up to 8A in single-module systems and supports 14A or 20A in redundant configurations.
- Redundancy Support: N+1 redundancy enhances system reliability for critical operations.
- Alarm Relay: Rated at 250VAC for efficient fault signaling.
- Scalable Design: Supports configurations with up to 4 units for high-output systems.
The Allen-Bradley 1771-P4R is an ideal choice for ensuring uninterrupted power supply in industrial PLC-5 systems. Its redundancy support and scalable output make it a reliable solution for mission-critical applications.
