Part #: 1783-BMS20CL Manufactured by: Allen-Bradley
Regular price
$1,647.00
Sale price
$1,647.00
Regular price
6 in Stock
Condition: New-Surplus Original Box
Shipping calculated at checkout.
Product Overview
The 1783-BMS20CL switch is an Allen-Bradley managed Ethernet switch with 20 ports.
We accept:
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Venmo
  • Visa
warranty
IQElectro 2-Year Warranty
Warranty for Product #: 1783-BMS20CL
IQElectro offers a free 2-year warranty on all products. You can trust that every purchase is a reliable investment in the future of your company. Warranty Terms
2-3 Day Free Shipping
Packed Ready to Ship
24/7 Expert Support
Return within 30-Days
IQElectro LLC BBB Business Review
IQElectro is Not an authorized distributor for Allen-Bradley
Original Manufacturer's Warranty Not Covered, This Product is SURPLUS.

Product Description P/N: 1783-BMS20CL

Description / Specifications

Description

The Allen-Bradley 1783-BMS20CL is an Allen-Bradley Stratix 5700 industrial managed Ethernet switch. This Ethernet switch is ideally used in implementing Ethernet I/P networks. It has Sixteen (16) Ports, composed of Twelve (12) Fast Ethernet Copper ports, Two (2) Gigabit Ethernet combo ports and Two (2) SFP slots for Fast Ethernet. This module is powered by an external supply of 24V DC.



Technical Specifications



Condition New / Never Used Surplus
Brand Allen-Bradley
Series Stratix 5700
Part Number 1783-BMS20CL
Wire size, ground connection 4.0 mm2 (12 AWG) min, stranded copper wire
Manufacturer Rockwell Automation
No. of Ports 20
No. of Fast Ethernet Copper Ports 16
No. of Gigabit combo Ports 2
Power Supply 12…48V DC
Power Dissipation 30 W
Wire size, Ethernet connection RJ45 connector according to IEC 60603-7, 2- or 4-pair Category 5e minimum cable according to TIA 568-B.1 or Category 5 cable according to ISO/IEC 24702
Wire size, DC power connection 0.5…0.8 mm2 (20…18 AWG) solid or stranded copper wire rated at 75 °C (167 °F) or greater, 1.2 mm (3/64 in.) insulation max, 6.3 mm (0.25 in.) ±0.5 mm (0.02 in.) strip length
Wire size, alarm connection 0.5…0.8 mm2 (20…18 AWG) solid or stranded, UL/CSA- rated style 1007 or 1569 twisted-pair copper appliance wiring material (AWM) wire, 6.3 mm (0.25 in.) ±0.5 mm (0.02 in.) strip length
Alarm Relay 1 A @ 30V DC or 0.5 A @ 48V DC
Product type Managed Ethernet switch
Fiber ports 2
Power input 12 to 48 Volts DC
Operating temperature -40 to 60 degrees Celsius





Information About 1783-BMS20CL

The 1783-BMS20CL switch is a 20-port Ethernet switch. In supervisor mode, the switch can gather information from the ring and can manage the DLR status and machine-level DLR diagnostics. The supervisor node also provides alternate routes when it detects a ring break. DLR is used in high-performance network applications that cannot tolerate network outage. Of the 20 switch ports, 16 are RJ45 Fast Ethernet ports, 2 are Fast Ethernet combo ports, and the remaining 2 are Fast Ethernet fiber ports.

The 1783-BMS20CL switch runs on DC input ranging from 12 to 48 Volts DC. The minimum and maximum current draw of the switch are 0.5 Amps and 3 Amps, respectively. A SELV or Class 2 power supply should be used for the switch power. The typical power consumed by the 1783-BMS20CL switch is 21 Watts at 40 degrees Celsius and 24 Volts DC. The peak power consumption of the switch can reach 30 Watts. For isolation voltage, the 1783-BMS20CL switch has been type tested at 850 Volts DC for 60 seconds. The 1783-BMS20CL switch comes in an open enclosure with the T4 IEC temperature code. The weight and dimensions of the 1783-BMS20CLswitch are 2.04 kilograms and 5.1 x 5 x 5.3 inches. The operating temperature range for the 1783-BMS20CL switch is from -40 to 60 degrees Celsius.

The Allen-Bradley 1783-BMS20CL is a managed Ethernet Switch that is part of the Stratix 5700 product category. This Ethernet switch supports a variety of topologies, including Device Level Ring (DLR) for resilient network.

This ethernet switch may be used to implement Common Industrial Protocol (CIP) over Ethernet. CIP is an industrial protocol supported by Open Device Vendor’s Association (ODVA), for communication with Logix controllers, for data exchange as well as interaction with visualization systems.

This managed Ethernet switch is provided with Twenty (20) ports composed of Sixteen (16) Fast Ethernet Copper ports (FE) supporting 10/100 Mbps, Two (2) Gigabit Ethernet compo ports supporting 1Gbps transmission speed and Two (2) Small Form-factor pluggable network interface slots for Fiber Optic, Gigabit Ethernet.

This managed Ethernet switch supports implementation of Linear, Star, Device Level Ring and other topologies to fit industrial Ethernet networking requirements. This managed Ethernet switch has Eight (8) Fast Ethernet copper ports and Two (2) Gigabit Ethernet ports.

This Ethernet switch does not require a backplane for installation. It is a stand-alone device externally powered by a power supply unit that provides 0.5…3.0 A maximum Current @ 12-48VDC Voltage range with Class 2/Safety Extra Low Voltage (SELV).

The 1783-BMS20CL has an open-type enclosure. It requires installation inside an enclosure that offers protection to field contaminants and elements such as dirt, dust, moisture, water and other elements. The module’s required operating temperature is -40…+60 Degree Celsius or -40…+140 Degree Fahrenheit with maximum surrounding air of 60 Degree Celsius or 140 Degree Fahrenheit.



Manufacturer information

Allen-Bradley, a brand of Rockwell Automation, specializes in manufacturing industrial automation equipment. The product range includes programmable logic controllers (PLCs), motion control systems, safety devices, motor control equipment, automation software, and HMI panels. Allen-Bradley products are known for their reliability and integration with other systems.

IQElectro is not an authorized distributor.
QElectro LLC (IQElectro) is NOT an Authorized Distributor or in any way affiliated with Rockwell Automation, Siemens, or any other Manufacturers. IQElectro is NOT an Authorized Dealer of this product. The product may be of older version, date codes, or design than that available from authorized dealers. As IQElectro is not an authorized dealer of this product, the Original Manufacturer's Warranty and Support DO NOT apply. IQElectro sells SURPLUS only and DOES NOT SELL SOFTWARE or FIRMWARE licenses For more detailed information, please refer to the full version of our disclaimer policy Disclaimer Policy.
