1783-ETAP1F | Allen-Bradley 3-Port Ethernet/IP Tap, 2 Copper + 1 Fiber
- Regular price
- $495.00
- Sale price
- $495.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 1783-ETAP1F
Description
The Allen-Bradley 1783-ETAP1F is a 3-port Ethernet/IP tap module that combines two copper ports and one fiber optic port for mixed-media industrial networking. Operating on 24 VDC, it provides dependable data transfer for controllers, HMIs, and Ethernet-enabled automation equipment.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Allen-Bradley |
| Category | Networks & Communication |
| Part Number | 1783-ETAP1F |
| Subcategory | Ethernet Tap Modules |
| Manufacturer | Rockwell Automation |
| Series | Embedded Switch |
| Module Type | Ethernet/IP Tap |
| Total Ports | 3 |
| Copper Ports | 2 (10/100 Mbps) |
| Fiber Port | 1 (100 Mbps, LC connector) |
| Supported Topologies | Linear, Star |
| Installation | DIN rail or panel mount |
| Installation Orientation | Horizontal / Vertical |
| Power Input | 20.4…27.6 VDC (24 VDC nominal) |
| Status Indicators | OK, Link1, Link2 LEDs |
| Material | Copper/Fiber construction |
| Network | Ethernet/IP |
| Dimensions | 5.16 in H × 1.36 in W × 4.13 in D (Length: 105 mm) |
| Weight | 1.1 lb |
Information About 1783-ETAP1F
The 1783-ETAP1F is part of Rockwell Automation’s Embedded Switch series, developed to extend Ethernet/IP networks with copper-to-fiber communication flexibility. With dual copper ports supporting auto-negotiation in full or half duplex modes and an LC fiber optic interface, the module enhances long-distance communication with strong resistance to electrical noise. Its compact design allows for external mounting without the need for a backplane, and installation clearances ensure proper fiber cable routing and bending radius. Featuring diagnostic LEDs for power and link status, the 1783-ETAP1F provides dependable network performance for controllers, HMIs, and other Ethernet-enabled industrial devices.
Key Features
- Media Conversion: Integrates two copper ports with one fiber optic port for flexible Ethernet/IP networking.
- Copper Connectivity: Supports 10/100 Mbps speeds with auto-negotiation and full/half duplex operation.
- Fiber Optic Port: Provides 100 Mbps transmission with extended distance capability and noise immunity.
- Mounting Options: Supports DIN rail or panel installation in both vertical and horizontal orientations.
- Power Input: Operates on 24 VDC nominal (20.4–27.6 VDC range).
- Diagnostic Indicators: Equipped with OK, Link1, and Link2 LEDs for status monitoring.
- Compact Design: External mounting without backplane simplifies integration in industrial enclosures.
- Industrial Application: Combines copper and fiber networks for robust automation system communication.
The 1783-ETAP1F delivers the reliability and precision required for hybrid Ethernet/IP networking in demanding industrial environments.
