1797-IRT8 | Allen Bradley FLEX Ex RTD Thermocouple I/O Module
- Regular price
- $4,363.00
- Sale price
- $4,363.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 1797-IRT8
Description
The Allen-Bradley 1797-IRT8 is a FLEX Ex RTD Thermocouple I/O Module with 8 configurable inputs. It supports a signal input range of 40-100 mV and operates with a settling time of 8 milliseconds, making it ideal for precise temperature measurement in hazardous environments.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Allen Bradley |
| Category | PLCs and Accessories |
| Part Number |
1797-IRT8 |
| Subcategory | PLC Expansion Modules |
| Product Type | FLEX Ex RTD Thermocouple I/O Module |
| Inputs | 8 |
| Input Type | Internal Bus Configurable |
| Signal Input Range | 40 to 100 millivolts |
| Lead Resistance Compensation | 15 Watts maximum |
| Settling Time | 8 milliseconds |
| Module Field-side Power Consumption | 1.6 Watts |
| Thermal Dissipation | 5.46 BTU/hour maximum |
| Power Supply | 9.5 Volts DC |
Information About 1797-IRT8
The 1797-IRT8 is a versatile RTD thermocouple I/O module from Allen-Bradley’s FLEX Ex series, designed for industrial applications requiring intrinsically safe operation. It features 8 inputs that are internally bus-configurable to handle a signal input range of 40 to 100 mV. The module includes lead resistance compensation up to 15 ohms, ensuring accurate readings in temperature monitoring applications. With a power supply of 9.5V DC and a field-side power consumption of 1.6W, the 1797-IRT8 is energy-efficient. Its thermal dissipation rating of 5.46 BTU/hour further supports stable operation in demanding environments.
Key Features:
- Inputs: 8 internally bus-configurable inputs for RTD or thermocouple connections.
- Signal Range: Supports a signal input range of 40-100 millivolts.
- Settling Time: Achieves precise measurements with an 8-millisecond settling time.
- Lead Resistance Compensation: Handles up to 15 ohms for enhanced accuracy.
- Power Efficiency: Consumes 1.6W with a thermal dissipation of 5.46 BTU/hour.
- Power Supply: Operates at 9.5V DC for reliable performance.
- Hazardous Location Use: Designed for intrinsically safe operation in hazardous environments.
The Allen-Bradley 1797-IRT8 is a dependable and accurate solution for temperature measurement, offering configurable inputs and robust performance for hazardous industrial applications.
