Part #: 193-1EFDB Manufactured by: Allen-Bradley
$79.00
$79.00
4 in Stock
Condition: New-Surplus Original Box
Shipping calculated at checkout.
Product Overview
Allen Bradley 193-1EFDB Bulletin 193 E100 IEC Solid State Overload Relay, Full Load Current Range 3.2-16A, 3 Phase, Overlo...  Read more
We accept:
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Venmo
  • Visa

Do you need help?

Call our Sales Manager
phone
+1 (828) 222-3490
Mon./Sat.: 7:00AM - 8:00PM
Write to us now
email
sales@iqelectro.com
Mon./Sat.: 7:00AM - 12:00PM
warranty
IQElectro 2-Year Warranty
Warranty for Product #: 193-1EFDB
IQElectro offers a free 2-year warranty on all products. You can trust that every purchase is a reliable investment in the future of your company. Warranty Terms
2-3 Day Free Shipping
Packed Ready to Ship
24/7 Expert Support
Return within 30-Days
IQElectro LLC BBB Business Review
IQElectro is Not an authorized distributor for Allen-Bradley
Original Manufacturer's Warranty Not Covered, This Product is SURPLUS.

Product Description P/N: 193-1EFDB

Description / Specifications

Description

IEC Overload Relay,Electronic,Selectable Trip Class 10 20 15 30,Selectable Manual or Auto Manual Reset,3.2 16.0 A,1 Normally Open Contact and 1 Normally Closed Contact,Mounts to 100 C09 to 100 C23 Contactor. The Allen-Bradley 193-1EFDB is an IEC rated electronic overload relay used for the protection of three-phase motors.



Technical Specifications

Brand Allen-Bradley
Manufacturer Rockwell Automation
Category Contactors & Starters
Subcategory Solid State Overload/Relay
Amperage 3.2-16 Amp
Part Number 193-1EFDB
Applications For Motor Overload Protection
Contact Configuration 1 NO, 1 NC
Enclosure Type NEMA
Number of Poles 3 Pole
Terminal Type Screw
Type Advanced, IEC, Manual/Automatic
Voltage 690 Volt
Range E100





Information About 193-1EFDB

The 193-1EFDB by Allen-Bradley is an E100 IEC Solid State Overload Relay tailored for motor overload protection. Operating within an amperage range of 3.2 to 16 Amp, it ensures precise and reliable protection for motors against overload conditions, safeguarding equipment and ensuring operational efficiency.

Featuring a contact configuration of 1 Normally Open (NO) and 1 Normally Closed (NC), this relay offers versatility in control and monitoring. Its NEMA enclosure type provides robust protection against environmental elements, ensuring durability and longevity in harsh industrial environments.

With three poles and a screw terminal type, the 193-1EFDB facilitates secure and efficient electrical connections, enhancing ease of installation and maintenance. Its advanced IEC design enables both manual and automatic operation, allowing for flexible control strategies to suit various application requirements.

Rated for a voltage of up to 690 Volts, this relay offers comprehensive protection across a wide range of electrical systems and installations. Tailored specifically for the E100 range, it ensures compatibility and seamless integration with Allen-Bradley's lineup of industrial automation products.

Overall, the 193-1EFDB E100 IEC Solid State Overload Relay stands as a reliable and effective solution for motor overload protection, offering advanced features, robust construction, and versatile functionality essential for industrial applications.
