193-EEEB | Allen-Bradley E1 Plus 5.4-27.0 Amp Overload Relay
- Regular price
- $549.00
- Sale price
- $549.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 193-EEEB
Description
The Allen-Bradley 193-EEEB is an adjustable electronic overload relay from the E1 Plus series, designed to protect three-phase motors operating between 5.4 and 27.0 Amps. It offers selectable trip classes and reset modes for flexible integration into motor control circuits.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Allen-Bradley |
| Category |
Contactors & Starters
|
| Part Number | 193-EEEB |
| Subcatecory |
Solid State Overload/Relay
|
| Amperage Range | 5.4 – 27.0 Amps |
| Number of Phases | 3 Phase |
| Voltage Rating | 600–690 VAC at 50/60 Hz |
|
Contact Configuration
|
1 NO, 1 NC |
| Reset Type | Selectable Manual or Auto-Manual |
| Trip Class | Selectable 10, 15, 20, 30 |
| Terminal Type | Screw Terminals |
| Contactor Compatibility | 100-C09 to 100-C23 Contactors |
| Certifications | CE, CSA, CCC, C-TICK, KC, MARINE |
| Weight | 0.5200 lb |
Information About 193-EEEB
The 193-EEEB E1 Plus overload relay is an IEC-type electronic protection device engineered for use with Allen-Bradley 100-C09 to 100-C23 contactors. It supports three-phase motor protection with a wide current adjustment range and selectable trip classes (10, 15, 20, 30), making it ideal for varying load conditions. The unit includes one normally open (NO) and one normally closed (NC) auxiliary contact, and supports both manual and auto-manual reset configurations.
Key Features:
- Wide Current Range: supports overload protection for motors between 5.4 and 27.0 Amps, suitable for mid-range motor applications.
- Selectable Trip Classes: configurable for Class 10, 15, 20, or 30 to match load behavior and protection requirements.
- Flexible Reset Options: allows manual or auto-manual reset for integration into various control schemes.
- Reliable Contact Configuration: includes 1 NO and 1 NC auxiliary contact for feedback or interlocking functionality.
- Global Compliance: meets CE, CCC, CSA, C-TICK, KC, and marine certification requirements for worldwide use.
- Contactor Compatibility: designed to mount directly to Allen-Bradley 100-C09 through 100-C23 IEC contactors.
The 193-EEEB provides dependable, configurable overload protection for industrial three-phase motors, with broad compatibility and international certification.
