194E-A16-1753 | Allen-Bradley 194E Load Switch

Description

The Allen-Bradley 194E-A16-1753 is a 16A, 3-pole load switch from the 194E series, designed for manual motor control and circuit isolation. It features a compact design, rotary operation, and is suitable for applications up to 690V AC, offering reliable performance in industrial environments.

Technical Specifications

Information About 194E-A16-1753

The Allen-Bradley 194E-A16-1753 is a 16-ampere, 3-pole load switch designed for industrial applications requiring reliable circuit isolation and manual motor control.

Key Features:

• Rated Operational Voltage (Ue): Up to 690V AC

• Continuous Current Rating (Ith): 16 A

• Motor Power Ratings:

  • Single-phase (AC-3):

    • 120V: 1 HP

    • 240V: 2 HP

  • Three-phase (AC-3):

    • 240V: 3 HP

    • 480V: 7.5 HP

    • 600V: 10 HP

• Short-Circuit Current Rating: 5 kA

• Mounting Style: Base/DIN rail mounting

• Switching Configuration: 2-position OFF-ON with a 90° switching angle

• Handle Compatibility: Compatible with various handle types, including Type N (yellow/red, 48mm x 48mm, IP66 protection)

• Safety Features:

  • IP20 finger-safe terminals

  • Padlockable handles accommodating up to 3 padlocks for enhanced safety during maintenance

• Additional Poles: Provision for adding a 4th pole (neutral)

• Auxiliary Contacts: Options for early break auxiliary contacts

• Terminal Covers: Available for enhanced protection

• Earth and Neutral Terminals: Optional add-ons for specific application requirements

This load switch is suitable for use as a local motor isolator and disconnect switch in various industrial environments, offering flexibility and reliability in motor control applications.
