2080-IQ4OB4 | Allen-Bradley Micro800 8-Ch Digital 12/24V DC Input/Output
- Regular price
- $184.00
- Sale price
- $184.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 2080-IQ4OB4
Description
The Allen-Bradley 2080-IQ4OB4 input and output module is a digital input and output module from the Micro 800 PLC series. It is a plug-in type of input and output module that is made to be plugged into a programmable logic controller or PLC to provide it with additional input and output points. The 2080-IQ4OB4 input and output module is approved for safe operation in hazardous locations in North America. This module has no built-in enclosure. The operating temperature for the 2080-IQ4OB4 input and output module is -4 to 149 degrees Fahrenheit and the storage temperature is -40 to 185 degrees Fahrenheit.
Technical Specifications
| Brand | Allen-Bradley |
| Manufacturer | Rockwell Automation |
| Part Number | 2080-IQ4OB4 |
| Product Type | Digital Plug-in Module |
| DC On-state Voltage min./max. | 9.0/30V DC |
| DC On-state Current min. | 2.0 mA at 9V DC |
| DC On-state Current nom. | 3.0 mA at 24V DC |
| DC On-state Current max. | 5.0 mA |
| DC Off-state Voltage max. | 5V DC |
| DC Off-state Current max. | 1.5 mA |
| IEC Input Compatibility | Type 3 |
| AC On-state Voltage min./max. | 10.25V AC/30V AC |
| AC On-state Current min./max. | 2mA at 9V AC/ 5.0 mA |
| Enclosure Type Rating | None(open-style) |
| Sourcing Output Power Supply Voltage min./max. | 10.8V DC/30V DC |
| Sourcing Output On-state Voltage min./nom./max. | 10V DC/24V DC/30V DC |
| Sourcing Output On-state Current min./max. | 5.0mA at 10V DC/ 0.5 A |
Information About 2080-IQ4OB4
The 2080-IQ4OB4 Micro800 Plug-in Modules is an I/O module with 4 channel inputs. This module features a source output, and it operates on 9 to 30 Volts DC, or 10.25 to 30 Volts AC. Manufactured by Allen-Bradley, the Micro800 plug-in modules, including the 2080-IQ4OB4, extend the functionality of the embedded I/O without increasing the footprint of the controller. The module enhances performance through the addition of extra capabilities or processing power, and it also adds some additional communication functions. The various plug-in modules that the Micro800 programmable controller series supports include the Micro810, Micro820, Micro830, and the Micro 850. The 2080-IQ4OB4 Micro800 accessories comprise a remote LCD which is compatible with the Micro820 only and a USB adapter that works well with the Micro810 only. It also comes with an LCD with a keypad that is compatible with the Micro810 only, and with an expansion power supply.
These plug-in modules are designed to enhance the functionality of the base unit controller. With modules like the 2080-IQ4OB4, users can extend the functionality of the embedded Inputs and outputs without increasing the controller footprint. Also, it is easy to improve performance through the addition of extra processing power or capabilities. The Micro800 plug-in modules can also help, especially with additional communication functions. With these plug-in modules, users can control and familiarize the base unit controller to help fit their application requirements. Additionally, they can increase the embedded I/O modules usability without increasing the size of the physical controller. In its place, users can enhance the abilities of the unit by adding a clock as well as memory modules to the system.
Manufacturer information
Allen-Bradley, a brand of Rockwell Automation, specializes in manufacturing industrial automation equipment. The product range includes programmable logic controllers (PLCs), motion control systems, safety devices, motor control equipment, automation software, and HMI panels. Allen-Bradley products are known for their reliability and integration with other systems.
