2098-IPD-005 | Allen-Bradley Servo Drive
- Regular price
- $5,024.00
- Sale price
- $5,024.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 2098-IPD-005
Description
The 2098-IPD-005 is an Ultra3000 Digital Servo Drive from Allen-Bradley, designed for high-performance motion control. It supports input power of 120/240V AC and delivers up to 5A continuous output current.
Technical Specifications
|
Condition |
New/Never Used Surplus |
|---|---|
| Brand | Allen-Bradley |
|
Category |
Drives |
|
Part Number |
2098-IPD-005 |
| Subcatecory |
Servo Drives & Controls
|
| Series | Ultra 5000 Drives |
| Output Current (Continuous) | 2.5 Amps (0-peak) |
| Nominal Input Current (AC) | 5 Amps Root Means Square |
| Input Frequency (AC) | 47-63 Hz |
| Input Voltage (AC) | 100-240 Voltage Root Means Square (Single Phase) |
| Weight | 1.22 kgs |
Information About 2098-IPD-005
The Allen-Bradley 2098-IPD-005 is an Ultra5000 Intelligent Positioning Drive designed for precise motion control in industrial applications. It integrates both drive and control functionalities, making it suitable for standalone, single-axis systems requiring high performance and reliability.
Key Features:
- Input Voltage: 100–240V AC, single-phase
- Input Frequency: 47–63 Hz
- Continuous Output Current: 2.5 A (0-peak)
- Peak Output Current: 7.5 A (0-peak)
- Continuous Output Power: 0.5 kW at 230V AC input
- User Program Memory: 512 KB
- Communication Interface: Direct DF-1 interface to PanelView
- Feedback Support: Compatible with absolute, sine/cosine, intelligent, and incremental encoders
- I/O Capabilities:
- 16 optically isolated 12–24V DC digital inputs
- 7 optically isolated 12–24V DC digital outputs
- 2 analog inputs (-10 to 10V range, 12-bit resolution)
- 2 analog outputs (-10 to 10V range, 12-bit resolution)
The Ultra5000 series is known for its integrated drive and controller packaging, which reduces system components and connections, thereby lowering costs. The 2098-IPD-005 model's automatic motor recognition capability enhances setup efficiency, and its compatibility with various encoder types allows for flexible feedback options.
