20BD096A0AYNAND0 | Allen-Bradley AC Drive
- Regular price
- $18,999.00
- Sale price
- $18,999.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 20BD096A0AYNAND0
Description
The Allen-Bradley 20BD096A0AYNAND0 is a 75 HP, 480V AC, 3-phase variable frequency drive (VFD) from the PowerFlex 700 series. Designed for high-performance motor control in industrial environments, it offers advanced vector control capabilities and robust protection features.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Allen-Bradley |
| Category |
Drives
|
| Part Number | 20BD096A0AYNAND0 |
| Subcatecory |
Drives
|
| Display Type | No HIM - Blank Plate |
|
Input Voltage |
480 V |
|
Size
|
Size 5 Frame |
| Standard | C-TICK,CE,CUL,GOST,MARINE,UL |
| Enclosure | IP20/NEMA/UL 1 |
| Output Current | 96 A |
| Split Crucible | N |
| Type | 20B |
| Weight | 96.00 lbs |
Information About 20BD096A0AYNAND0
The Allen-Bradley 20BD096A0AYNAND0 is a 75 HP, 480V AC variable frequency drive from the PowerFlex 700 series, designed to deliver high-performance motor control in industrial applications. With advanced vector control, integrated dynamic braking capabilities, and a modular architecture, it supports precise speed and torque regulation for demanding loads such as fans, pumps, and conveyors. This drive is well-suited for applications requiring flexibility, scalability, and long-term reliability.
Key Features:
- Product Type: AC Variable Frequency Drive (VFD)
- Series: PowerFlex 700
- Horsepower Rating: 75 HP (Normal Duty), 60 HP (Heavy Duty)
- Input Voltage: 480V AC, 3-phase
- Output Current: 96 Amps
- Frame Size: 5
- Control Method: Vector Control (sensorless and flux vector)
- Brake IGBT: Installed
- Brake Resistor: Not included
- I/O Voltage: 115V AC
- Operator Interface: Blank cover (no HIM module included)
- Communication Module: Not included (optional)
- Enclosure Type: IP20 / NEMA Type 1 with conformal coating
- EMC Compliance: CE EMC Directive 89/336/EEC – Second Environment Filter
- Operating Temperature: 0 to 50 °C (32 to 122 °F)
- Storage Temperature: -40 to 70 °C (-40 to 158 °F)
- Relative Humidity: 5% to 95%, non-condensing
- Maximum Elevation: 1000 meters (3280 feet) without derating
- Certifications: UL Listed, CSA Certified, CE Marked, RoHS Compliant
This drive is ideal for industrial environments requiring efficient and reliable motor control, especially in applications with dynamic load profiles.
