20F1AND248JN0NNNNN | Allen-Bradley PowerFlex 753 AC Drive
- Regular price
- $8,499.00
- Sale price
- $8,499.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 20F1AND248JN0NNNNN
Description
The Allen-Bradley 20F1AND248JN0NNNNN VFD is rated for an output of 248 A and is housed in an enclosure rated IP20/IP00. It includes an optional communication slot and supports a voltage rating of 480VAC or 650V DC, operating with AC input only and no DC Bus. This Allen Bradley/Rockwell Automation variable frequency drive is designed for applications requiring 200 horsepower.
Technical Specifications
| Brand | Allen-Bradley |
| Category | Drives |
| Part Number | 20F1AND248JN0NNNNN |
| Subcategory | Drive |
| Manufacturer | Rockwell Automation |
| Series | PowerFlex 753 |
| Frames | 6...8 |
| Enclosure Type | AC Input w/Precharge, no DC Terminals |
| Frames 2 | 2...7 |
| Enclosure Type 2 | IP20/IP00, NEMA/UL Type Open |
| Voltage | 480V AC/650V DC |
| Filtering | Yes |
| Default CM Cap Connection | Jumper Installed |
| Internal Resistor | No |
| Internal Transistor | No |
Information About 20F1AND248JN0NNNNN
The 20F1AND248JN0NNNNN drive, a PowerFlex 753 AC drive from Allen-Bradley, is a versatile and robust solution for various applications. It supports multiple languages and complies with various standard certifications, ensuring ease of integration into machine systems. It facilitates seamless connectivity with other Allen-Bradley devices via serial communication and features a built-in I/O port to accommodate diverse application needs.
This drive includes an integrated AC input with precharge, eliminating the need for an external power source. It is housed in an IP20/IP00 rated enclosure, suitable for NEMA/UL Open Type installations. Operating at 480 Volts AC or 650 Volts DC, it delivers a current rating of 248 Amps and provides a power output of 200 Horsepower under standard conditions, with a frequency of 60 Hertz.
The 20F1AND248JN0NNNNN drive meets EMC requirements and offers options for filtering and CM Cap configurations, with a jumper for the CM cap installed. Notably, it lacks internal resistors and transistors, hence dynamic braking is not supported. Additionally, it does not include a human-machine interface module on the front panel.
Equipped with isolation transformers, input line reactors, and an external common mode choke, this drive employs advanced motor control algorithms to regulate torque and speed for 3-phase induction motor applications. Optional accessories like output reactors, terminators, and reflected wave devices can be added as needed.
Manufacturer information
Allen-Bradley, a brand of Rockwell Automation, specializes in manufacturing industrial automation equipment. The product range includes programmable logic controllers (PLCs), motion control systems, safety devices, motor control equipment, automation software, and HMI panels. Allen-Bradley products are known for their reliability and integration with other systems.
