2198-D032-ERS4 | Allen-Bradley Kinetix 5700 Dual-Axis Safe Speed Drive, 2×13 A
- Regular price
- $3,197.00
- Sale price
- $3,197.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: 2198-D032-ERS4
Description
The Allen-Bradley 2198-D032-ERS4 is a high-performance Kinetix 5700 dual-axis inverter drive designed for EtherNet/IP motion applications. Each axis delivers 13 A continuous current (18.3 A peak) and supports demanding multi-axis systems with advanced control loop bandwidths of 400 Hz velocity and 1000 Hz current response. This drive enhances machine throughput while maintaining precise and safe servo operation.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Allen-Bradley |
| Manufacturer | Rockwell Automation |
| Part Number | 2198-D032-ERS4 |
| Series / Product Line | Kinetix 5700 Servo Drives |
| Module Type | Dual-Axis Inverter |
| Input Voltage (AC) | 324…528 V AC, 3-Phase |
| DC Bus Input Range | 458…747 V DC |
| Continuous Output Current (per axis) | 13 A rms |
| Peak Output Current (per axis) | 18.3 A (0-pk) |
| Continuous Power Output (nominal) | 8.9 kW |
| Velocity Loop Bandwidth | 400 Hz |
| Current Loop Bandwidth | 1000 Hz |
| AC Input Frequency | 4 kHz |
| DC Input Current | 13.7 A DC |
| Internal Bus Capacitance | 390 µF |
| Communication | EtherNet/IP Integrated Motion |
| Mounting | Zero-stacking, panel mount |
| Product Category | Multi-Axis Servo Control |
Information About 2198-D032-ERS4
The 2198-D032-ERS4 is part of the Allen-Bradley Kinetix 5700 drive family, designed to provide high-performance motion control for multi-axis applications. This dual-axis inverter operates on a three-phase 324–528 VAC supply and supports DC input voltages between 458–747 VDC with a current draw of 13.7 A. It features advanced EtherNet/IP connectivity for seamless integration into Logix-based systems, enabling coordinated motion control across complex machines. Each axis provides 13 A continuous current (18.3 A peak) with a built-in velocity loop bandwidth of 400 Hz and current loop bandwidth of 1000 Hz for responsive and precise control. The drive incorporates 390 μF internal capacitance and supports high-frequency operation at 4 kHz AC input frequency. Its compact design includes zero-stacking mounting capability, allowing side-by-side installation without additional clearance. With rugged construction and advanced networking, the 2198-D032-ERS4 enables scalable, space-saving motion solutions in high-demand industrial environments.
Key Features:
- Dual-Axis Inverter: Provides simultaneous control of two motion axes for compact system designs.
- Power Range: Operates on 324–528 VAC three-phase supply with 8.9 kW continuous power output.
- Current Capacity: Delivers 13 A continuous rms current and 18.3 A peak per axis.
- Bandwidth Performance: High-speed control with 400 Hz velocity loop and 1000 Hz current loop bandwidth.
- DC Input: Accepts 458–747 VDC input with 13.7 A DC current draw.
- Internal Design: Built-in 390 μF capacitance for stable energy buffering and regulation.
- Communication: EtherNet/IP connectivity ensures integration with Logix-based controllers for coordinated motion.
- Mounting: Zero-stacking capability allows installation next to other components without spacing.
- Frequency: Supports 4 kHz AC input frequency for high-response motion control.
- Application Use: Ideal for large-scale machines with multiple high-power motion axes.
The 2198-D032-ERS4 delivers the reliability and precision required for high-performance motion control in industrial automation systems.
