2198-E4004-ERS | Allen-Bradley Kinetix 5100 Servo Drive, 480V 3-Phase, 0.4kW
- Regular price
- $1,134.00
- Sale price
- $1,134.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 2198-E4004-ERS
Description
The Allen-Bradley 2198-E4004-ERS Kinetix 5100 drive is an AC indexing servo drive. It supports Dual-Ethernet connectivity. The rated output power of the 2198-E4004-ERS drive is 0.4 kilowatts.
Technical Specifications
| Brand | Allen-Bradley |
| Manufacturer | Rockwell Automation |
| Series | Kinetix 5100 |
| Part Number | 2198-E4004-ERS |
| Product Type | AC Servo Drive |
| Mounting Orientation | Vertical |
| Cooling | Natural Convection |
| Output Power | 0.4 Kilowatts |
| Input Voltage | 342 to 528 Volts AC |
| Output Current | 1.6 Amps |
| Peak Output Current | 5.4 Amps |
| Safe Torque-Off | Yes |
| Display | Yes |
| Keypad | Yes |
Information About 2198-E4004-ERS
The Allen-Bradley 2198-E4004-ERS indexing servo drive is an industrial AC-powered servo drive from the Kinetix 5100 series. The users can deploy the drive for motor control in industrial and commercial applications. The Kinetix 5100 series drives are compatible with a wide range of motors from Allen-Bradley. A salient feature of the Kinetix 5100 drives like the 2198-E4004-ERS drive includes support for Dual-Ethernet connectivity. The 2198-E4004-ERS drive operates with 342 to 528 Volts AC 3-phase input voltage. The output specifications of the drive are 0.4 kilowatts of output power, 1.6 Amps of output current and 5.4 Amps of peak output current. The operators can connect the drive to an Ethernet/IP module or controller in certain systems. The 2198-E4004-ERS indexing servo drive’s parameters are stored in its non-volatile memory.
The Allen-Bradley 2198-E4004-ERS Kinetix 5100 series servo drive supports a digital display and a keypad. The operators can set and edit the network parameters with the keypad. The 2198-E4004-ERS drive is suited to multiple motion control applications. The high-speed position capture (HCAP) function uses high-speed digital input to rapidly capture motor position data and store it for future use. The high-speed position compare function compares the actual motor position with the stored position data. The electronic camming feature supported by the drive enables non-linear electronic gearing between the motor and a master device. The 2198-E4004-ERS drive supports a hardwired Safe Torque-Off (STO) connector. The STO connector on the drive is used for wiring external devices and cascading safety connections between drives. The 2198-E4004-ERS drive and associated machinery must be professionally installed. The drive should only be operated under the specified ambient conditions.
Manufacturer information
Allen-Bradley, a brand of Rockwell Automation, specializes in manufacturing industrial automation equipment. The product range includes programmable logic controllers (PLCs), motion control systems, safety devices, motor control equipment, automation software, and HMI panels. Allen-Bradley products are known for their reliability and integration with other systems.
