Part #: 2198-H015-ERS2 Manufactured by: Allen-Bradley
$1,425.00
$1,425.00
4 in Stock
Condition: New – Open box
Shipping calculated at checkout.
Product Overview
The Allen-Bradley 2198-H015-ERS2 Kinetix 5500 Servo Drive exhibits 7.1 Amperes Continuous Output Current (0-peak), 12.5 Am...  Read more
We accept:
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Visa

Do you need help?

Call our Sales Manager
phone
+1 (828) 222-3490
Mon./Sat.: 7:00AM - 8:00PM
Write to us now
email
sales@iqelectro.com
Mon./Sat.: 7:00AM - 12:00PM
warranty
IQElectro 2-Year Warranty
Warranty for Product #: 2198-H015-ERS2
IQElectro offers a free 2-year warranty on all products. You can trust that every purchase is a reliable investment in the future of your company. Warranty Terms
2-3 Day Free Shipping
Packed Ready to Ship
24/7 Expert Support
Return within 30-Days
IQElectro is Not an authorized distributor for Allen-Bradley
Original Manufacturer's Warranty Not Covered, This Product is SURPLUS.

Product Description P/N: 2198-H015-ERS2

Description / Specifications

Description

The Allen-Bradley 2198-H015-ERS2 is a Kinetix 5500 servo drive designed for integrated motion control with CompactLogix 5370 controllers over EtherNet/IP. It supports three-phase input ranges of 195–264 V and 324–528 V, delivering continuous output power from 1.5 kW to 3.2 kW depending on the supply voltage. With advanced motion bandwidth, dual Ethernet ports, and integrated Safe Torque-Off, the 2198-H015-ERS2 provides a high-performance solution for coordinated servo applications.





Technical Specifications

Condition New/Never Used Surplus
Brand Allen-Bradley
Category Servo Drive
Part Number 2198-H015-ERS2
Subcategory Kinetix 5500 Servo Drive
Manufacturer Rockwell Automation
Product Category Kinetix 5500
Input Voltage 195–264 V rms (240 V nom), 324–528 V rms (480 V nom), 3-phase
Input Frequency 47–63 Hz
Continuous Output Power 1.5 kW (240 V), 3.2 kW (480 V)
Continuous Output Current (rms) 7.1 A
Continuous Output Current (0-pk) 5.0 A
Peak Output Current (rms) 17.7 A
Peak Output Current (0-pk) 12.5 A
Efficiency 97%
Velocity Loop Bandwidth 300 Hz
Current Loop Bandwidth 1000 Hz
Integrated Safety Safe Torque-Off (STO) Over Ethernet/IP
Hardwired Safety Not Supported
Internal Shunt Power 50 W
Short-Circuit Rating 200,000 A (rms) symmetrical
Frame Size Frame 2
Dimensions 2.16 × 8.90 × 10.43 in (55 × 226 × 265 mm)
Network Topologies Linear, Star, Device Level Ring (DLR)
Nominal Drive Voltage 240 V single-phase; 240/480 V three-phase
Motor Feedback 2-pin MF connector (supported)
Mounting Feature Zero-stack capable





Information About 2198-H015-ERS2

The 2198-H015-ERS2 is part of the Kinetix 5500 family, engineered for digital motion control requiring fast response and seamless EtherNet/IP integration. Designed for use with CompactLogix 5370 controllers, it enables configuration of velocity, torque, and position loop control for a wide range of servo axes. This servo drive provides continuous current ratings suitable for medium-power servo motors and includes dual Ethernet ports supporting linear, star, and Device Level Ring topologies. With integrated functional safety over Ethernet/IP and support for shared DC bus installations, the 2198-H015-ERS2 delivers versatile performance for multi-axis automation systems.

Key Features

  • EtherNet/IP integrated motion: Direct compatibility with CompactLogix 5370 controllers for coordinated motion control.
  • Wide input voltage support: Operates on 195–264 V and 324–528 V three-phase supplies.
  • High-performance control loops: Offers 1000 Hz current bandwidth and 300 Hz velocity bandwidth for precise motion regulation.
  • Integrated safety features: Supports Safe Torque-Off (STO) via Ethernet/IP for machine-level safety compliance.
  • Dual Ethernet ports: Enables linear, star, and DLR network topologies without external adapters.
  • Built-in internal shunt resistor: Provides 50 W dissipation for regenerative energy handling.
  • Zero-stack mounting: Allows compact installation and shared-bus configurations for multi-axis systems.
  • Robust industrial design: High short-circuit rating of 200 kA for demanding servo environments.

The 2198-H015-ERS2 delivers the reliability and precision required for advanced servo motion, multi-axis machine systems, and high-performance EtherNet/IP automation.

Frequently Asked Questions about 2198-H015-ERS2
Question: How does the 2198-H015-ERS2 integrate into an EtherNet/IP network?
Date Update:11/06/2025
Answer:

This drive features dual built-in Ethernet ports that allow it to connect easily to an EtherNet/IP network. These ports support various topologies, including Linear, Star, and Device Level Ring (DLR), providing flexibility in network design and ensuring reliable communication. With integrated support for Integrated Motion on EtherNet/IP, it allows seamless coordination with other drives and controllers on the same network.

Question: Can the 2198-H015-ERS2 handle both low and high-voltage power systems?
Date Update:11/06/2025
Answer:

Yes, the 2198-H015-ERS2 is designed to operate with both low-voltage (195–264V) and high-voltage (324–528V) three-phase power systems, making it versatile for a variety of industrial settings. This flexibility allows users to standardize on a single drive model across different parts of a facility or even in different regions with varying power supply standards. It supports nominal voltages of 240V and 480V, providing consistent and reliable performance across these voltage ranges.

Question: Which safety features are included with the 2198-H015-ERS2?
Date Update:11/06/2025
Answer:
  • Integrated Safety Over EtherNet/IP: Supports Safe Torque-Off (STO) functionality, which allows safe shutdown of the drive without completely disconnecting the power supply.
  • Short-Circuit Current Rating: 200,000 A (rms) symmetrical for enhanced system protection.
  • Internal Shunt Resistor: Dissipates excess energy to protect the drive and motor.
    These features help ensure operator safety and system reliability.
Question: How much output power and current does the 2198-H015-ERS2 provide?
Date Update:11/06/2025
Answer:
  • Continuous Output Current (rms): 13.0 A
  • Peak Output Current: 32.5 A
  • Output Power: 4.0kW to 8.3kW, depending on input voltage

These ratings make it suitable for a variety of medium-to-high performance servo motor applications.

Question: Is the 2198-H015-ERS2 still in production?
Date Update:11/06/2025
Answer:

Yes, according to Rockwell Automation, the 2198-H015-ERS2 is still in production and has an Active lifecycle status. It is available for purchase and fully supported, making it a reliable choice for new and existing automation projects.
