Part #: 2198-H025-ERS2 Manufactured by: Allen-Bradley
$1,495.00
$1,495.00
4 in Stock
Condition: New-Surplus Original Box
Shipping calculated at checkout.
Product Overview
Allen Bradley 2198-H025-ERS2 Kinetix 5500 Servo Drive, 190-528V AC 3 Phase Input, 20A Peak Current Output, Integrated Safe...  Read more
We accept:
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Venmo
  • Visa

Do you need help?

Call our Sales Manager
phone
+1 (828) 222-3490
Mon./Sat.: 7:00AM - 8:00PM
Write to us now
email
sales@iqelectro.com
Mon./Sat.: 7:00AM - 12:00PM
warranty
IQElectro 2-Year Warranty
Warranty for Product #: 2198-H025-ERS2
IQElectro offers a free 2-year warranty on all products. You can trust that every purchase is a reliable investment in the future of your company. Warranty Terms
2-3 Day Free Shipping
Packed Ready to Ship
24/7 Expert Support
Return within 30-Days
IQElectro LLC BBB Business Review
IQElectro is Not an authorized distributor for Allen-Bradley
Original Manufacturer's Warranty Not Covered, This Product is SURPLUS.

Product Description P/N: 2198-H025-ERS2

Description / Specifications

Description

The Allen-Bradley 2198-H025-ERS2 Kinetix 5500 Servo Drive exhibits 11.5 Amperes Continuous Output Current (0-peak), 20 Amperes Peak Output Current, and Integrated Safety Over Ethernet/IP.



Technical Specifications



Brand Allen-Bradley
Manufacturer Rockwell Automation
Part Number 2198-H025-ERS2
Product Category Kinetix 5500
Internal shunt power 50 W
Integrated Safety Over Ethernet I/P Supported
Short-circuit current rating 200,000 A (rms) symmetrical
Efficiency 97%
Current Loop 1000 Hz
Velocity Loop 300 Hz
Peak Output Current (rms) 17.7 A
Peak Output Current (0-peak) 12.5 A
Continuous Output Current (rms) 7.1 A
Continuous Output Power 1.5 KW at 195…264V rms, three-phase; 3.2 kW at 324…528V rms, three-phase;
Input Frequency 47…63 Hz
Main AC input Current 5.20 A @ 240 V; 3.40 A @ 480V
Continuous Output Current (0-peak) 5.0 A
Input Voltage 195…264V rms, three-phase (240V nom); 324…528V rms, three-phase (480V nom);
Hardwired Safety No
Dimensions 2.16 x 8.90 x 10.43 in (55 x 226 x 265 mm)
Integrated Safety Over Ethernet/IP Yes
Nom Drive Voltage 240/480 V (Three Phase)
Peak Output Current 20 Amperes
Frame Size Frame Size 2





Information About 2198-H025-ERS2

The Kinetix 5500 Ethernet I/P servo drive from Allen-Bradley with catalog number 2198-H025-ERS2 features compatibility with Two (2) input supply voltage ranges such as 195-264V rms, 3-phase and 324-528V rms, 3-phase, having a nominal voltage level of 240VAC and 480VAC, respectively. This drive delivers continuous output current of 8.0 A, peak output Current of 11.3 A, peak output current current (rms) of 20.0 A and 0-pk output current of 28.3 A along output power of 2.4 kW at 195-264V, 3-phase supply voltage and 5.1 kW at 324-528V, 3-phase.

This Kinetix drive is a frame 2 drive having physical dimensions of 225 mm (8.86 in) for height; 55 mm (2.16 in) for Width and 226 mm (8.90 in) for depth. This drive has an operating temperature ranges of 0…50 °C (32…122 °F) when installed with the 2198-KITCON-DSL connector kit and 0…40 °C (32…104 °F) when installed with a 2198-H2DCK converter kit and the existing 2090-CPBM7DF motor power/brake cable and 2090-CFBM7DF motor feedback cable. When storing this drive, the typical storage temperature is -40…+70 °C (-40…+158 °F). The relative humidity for both conditions is 5-95%.

Mechanical characteristics of the motor includex operating vibration of 5…55 Hz @ 0.35 mm (0.014 in.) double amplitude, continuous displacement; 55…500 Hz @ 2.0 g peak constant acceleration while operating shock is 15 g, 11 ms half-sine pulse (3 pulses in each direction of 3 mutually perpendicular directions). The drive comes with a protection class of IP 20 and carries certifications from cULus, CE, Functional Safety, RCM, KC, ODVA and OSHA.

This drive is compatible with controllers such as Compact GuardLogix 5570 or GuardLogix 5570, for issuing STO commands over an Ethernet/IP network. This feature provides a safe power-off action for the inverter transistors when receiving a monitored digital input. The drive supports motion and safety connection modes as well as a safety-only mode. When managing safety-only or both safety and motion, the Safety Network Number is automatically populated. To start and configure, the 2198-H025-ERS2 servo drive is located in the Controller Organizer of the Ethernet category, under the I/O Configuration folder. This module supports both bus-sharing multi-axis settings and standalone units, with an easy installation process and user-friendly operation. Installations that it can be configured for include shared AC/DC hybrid installations, multi-axis shared AC/DC, shared AC or shared DC. To dissipate excess energy, the servo drive has internal shunt resistor.



Manufacturer information
