22C-D038A103 | Allen-Bradley PowerFlex 400 Fan & Pump Drive 480VAC 3PH 38A 25HP
22C-D038A103 | Allen-Bradley PowerFlex 400 Fan & Pump Drive 480VAC 3PH 38A 25HP
Part #: 22C-D038A103 Manufactured by: Allen-Bradley

22C-D038A103 | Allen-Bradley PowerFlex 400 Fan & Pump Drive 480VAC 3PH 38A 25HP

Regular price
$1,599.00
Sale price
$1,599.00
Regular price
Never Used Surplus
1 in Stock
Shipping calculated at checkout.
Product Overview
This PowerFlex 400 AC Drive is a 25 HP (18.5 KW) VFD. This VFD has an IP rating of IP30 and is an 38 Amp Fan/Pump Control...  Read more
We accept:
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Meta Pay
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Venmo
  • Visa
IQElectro LLC BBB Business Review
warranty
Product comes with IQElectro 2-Year Warranty
Warranty for item #: 22C-D038A103
IQElectro offers a complimentary 2-year warranty on all our products. This ensures that every purchase you make from IQElectro is a reliable and trustworthy investment for the future of your company. Warranty Terms
IQElectro is NOT an authorized distributor for Allen-Bradley
Original Manufacturer's Warranty Not Covered, This Product is SURPLUS.
22C-D038A103 | Allen-Bradley PowerFlex 400 Fan & Pump Drive 480VAC 3PH 38A 25HP
    22C-D038A103 | Allen-Bradley PowerFlex 400 Fan & Pump Drive 480VAC 3PH 38A 25HP
22C-D038A103 | Allen-Bradley PowerFlex 400 Fan & Pump Drive 480VAC 3PH 38A 25HP
Return/Exchange within 30-Days.
If any product is damaged upon delivery, you may request an Exchange or Refund within 30 days of receiving your order.
2-3 Day Free Shipping
IQElectro provides free shipping within 2-3 days from the moment the order is placed on our website.

Product Description P/N: 22C-D038A103

Description / Specifications

Description

The Allen-Bradley 22C-D038A103 is a PowerFlex 400 Variable Frequency Drive (VFD). This VFD is specifically compatible for industrial fan and pump applications. It is powered with an input voltage range of 342-528VAC, 3-phase with applicable motor output of 38.0 A and Power of 18.5kW (25.0 HP).



Technical Specifications



Brand Allen-Bradley
Manufacturer Rockwell Automation
Part Number 22C-D038A103
Input Phase 3-Phase
Optional communication protocols BacNet; LonWorks; ProfiBus; Ethernet; DeviceNet; ControlNet
Built-in communication port RS485
Enclosure Rating IP20 / NEMA UL Open Type
Installation Panel Mount
Embedded I/O Discrete Inputs: Seven (7) Sink / Source Discrete Outputs: One (1) Open Output; Two (2) Form C Contacts Analog Input: Two (2) Analog Input 0-10VDC; 0- 20mA Analog Output: Two (2) Analog Input 0-10VDC; 0- 20mA
Control Method V/Hz, Slip compensation, Process PID
Applicable Motor Rating 25 HP (18.5 KW)
Output Current 38 A
Output Voltage 0-460VAC
Input Current 40 A
Input Voltage 342-528VAC
Product Line Powerflex 400
Drive Type Fan & Pump
Horsepower 25
Phase Three-Phase
Enclosure Panel Mount - IP30, NEMA/UL Type 1
Amperage 38 Amps





Information About 22C-D038A103

The 22C-D038A103 AC Powerflex 400 Drive by Allen Bradley has an output rating of 18.5 kW at 25 Horsepower, with an Amperage of 38, consistent over a 5-degree temperature change between 45 and 50 degrees Celsius. Recommended motor circuit protection is 140M-F8E-C45 with a 100-C60 contactor and a minimum enclosure volume of 9086 square inches. It dissipates around 606 Open IP20 Watts and has 50 fuses.

The 22C-D038A103 is a Frame D drive with enclosure rating of IP30, NEMA/UL Type 1 with no flange mount. When terminating I/O signals to the drive, maximum wire size is 33.6 mm sq. (or 2 AWG). (Wire cannot be smaller than 8.4 millimeters squared, or 8 AWG). Wiring Torque is 5.1 N-m, or 45 pounds to an inch.

This unit has an integral LCD keypad with two rows of 16 characters each and 5 LED indicator lights. This integral keypad allows local monitoring and control such as start and speed commands. Through this unit’s featured Auxiliary Motor Control system, up to three additional line-started motors can be controlled side by side with the central motor, which would be controlled directly by the 22C-D038A103 Powerflex drive. Use of this system can result in up to a 400% output, where the drive-controlled motor and all three of the additional motors are operating at their maximum speeds. This system can also be automated, causing the additional motors to begin operating as soon as demand increases beyond the capabilities of the first motor.

This Serial (RS485) drive supports FLN, DSI, Modbus RTU and Metasys N2 as standard communication protocols. It also supports several optional protocols, including ControlNet, LonWorks, Ethernet/IP and Device Net.

The 22C-D088A103 is applicable for AC motors rated 18.5kW or 25.0 HP. The input voltage requirement of this adjustable frequency AC drive is 340-528VAC, 3-Phase, input current of 40 Amperes and frequency range of 48-63 Hz. This drive supports panel mounting application within an enclosure that provides adequate protection from common contaminants such as corrosive air or gas, water, dust, oil and grease. This drive also requires external protection devices such as DC link chokes, EMC filters, AC line reactors, Harmonic filters, fuse and other electrical protection devices to maximize the drive’s operation lifespan.

Specifically, the recommended Allen-Bradley Filter for the 22C-D088A103 has a catalog number of 22-RFD100 with motor cable connection not exceeding 50 meters. Applicable fuse rating is 125 Amperes, while recommended motor contactor is 100-D110.

The 22C-D088A103 may be configured and operated using the embedded keypad and LCD readout that comes along with the drive. Remote mounted and remote handheld Human Interface Module (HIM) may also be installed with the drive to allow convenient configuration and operation means.
