22F-D6P0N103 | Allen-Bradley AC Drive
- Regular price
- $547.00
- Sale price
- $547.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 22F-D6P0N103
Description
The Allen-Bradley 22F-D6P0N103 is a compact, adjustable frequency AC drive from the PowerFlex 4M series, designed for efficient motor speed control in industrial applications.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Allen-Bradley |
| Category |
Drives
|
| Part Number | 22F-D6P0N103 |
| Subcatecory |
Drives
|
| Amperage | 6 Amp |
|
Connection Type |
Fixed Terminal Block |
| Enclosure Rating | IP20 |
| Frequency | 50-60 Hz |
| Mounting Type | Panel Mount |
| Power Factor | 0.98 |
| Standard | C-TICK,CE,CUL,GOST,KC,UL |
| Enclosure | IP20,UL-NEMA Type Open |
| Input Voltage | 480 V |
| Power Rating | 2.2 kW |
| Weight | 3.30 lbs |
Information About 22F-D6P0N103
The Allen-Bradley 22F-D6P0N103 is a compact adjustable frequency AC drive from the PowerFlex 4M series, designed for controlling the speed of three-phase induction motors in light industrial applications. It provides reliable, efficient motor control with essential features for integration into automation systems, offering flexibility in both standalone and networked environments.
Key Features:
- Product Type: AC Drive (Variable Frequency Drive)
- Series: PowerFlex 4M
- Output Power: 2.2 kW (3 HP)
- Output Current: 6.0 A
- Input Voltage: 480V AC, 3-phase
- Control Method: Volts-per-Hertz (V/Hz)
- Enclosure Type: Open-type (IP20)
- Display Interface: Fixed keypad with LED display for monitoring and programming
- Communication Interface: Integrated RS-485 (Modbus RTU)
- Mounting Type: Panel mount
- Operating Temperature: -10 to 50 °C (14 to 122 °F)
- Certifications: UL Listed, cULus, CE Marked
This drive is ideal for general-purpose motor control in conveyors, pumps, fans, and machine-level automation, providing a cost-effective solution with simple configuration and reliable performance. Its integration capabilities and compact size make it suitable for both new installations and retrofit applications.
Description
The Allen-Bradley 22F-D6P0N103 is a compact, adjustable frequency AC drive from the PowerFlex 4M series, designed for efficient motor speed control in industrial applications.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Allen-Bradley |
| Category |
Drives
|
| Part Number | 22F-D6P0N103 |
| Subcatecory |
Drives
|
| Amperage | 6 Amp |
|
Connection Type |
Fixed Terminal Block |
| Enclosure Rating | IP20 |
| Frequency | 50-60 Hz |
| Mounting Type | Panel Mount |
| Power Factor | 0.98 |
| Standard | C-TICK,CE,CUL,GOST,KC,UL |
| Enclosure | IP20,UL-NEMA Type Open |
| Input Voltage | 480 V |
| Power Rating | 2.2 kW |
| Weight | 3.30 lbs |
Information About 22F-D6P0N103
The Allen-Bradley 22F-D6P0N103 is a compact adjustable frequency AC drive from the PowerFlex 4M series, designed for controlling the speed of three-phase induction motors in light industrial applications. It provides reliable, efficient motor control with essential features for integration into automation systems, offering flexibility in both standalone and networked environments.
Key Features:
- Product Type: AC Drive (Variable Frequency Drive)
- Series: PowerFlex 4M
- Output Power: 2.2 kW (3 HP)
- Output Current: 6.0 A
- Input Voltage: 480V AC, 3-phase
- Control Method: Volts-per-Hertz (V/Hz)
- Enclosure Type: Open-type (IP20)
- Display Interface: Fixed keypad with LED display for monitoring and programming
- Communication Interface: Integrated RS-485 (Modbus RTU)
- Mounting Type: Panel mount
- Operating Temperature: -10 to 50 °C (14 to 122 °F)
- Certifications: UL Listed, cULus, CE Marked
This drive is ideal for general-purpose motor control in conveyors, pumps, fans, and machine-level automation, providing a cost-effective solution with simple configuration and reliable performance. Its integration capabilities and compact size make it suitable for both new installations and retrofit applications.
