Part #: 2711P-T6C5D8 Manufactured by: Allen-Bradley
$2,349.00
$2,349.00
4 in Stock
Condition: New-Surplus Original Box
Shipping calculated at checkout.
Product Overview
The Allen-Bradley 2711P-T6C5D8 PanelView Plus 6 600 provides a compact touchscreen HMI solution with flexible connectivity...  Read more
We accept:
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Visa

Do you need help?

Call our Sales Manager
phone
+1 (828) 222-3490
Mon./Sat.: 7:00AM - 8:00PM
Write to us now
email
sales@iqelectro.com
Mon./Sat.: 7:00AM - 12:00PM
warranty
IQElectro 2-Year Warranty
Warranty for Product #: 2711P-T6C5D8
IQElectro offers a free 2-year warranty on all products. You can trust that every purchase is a reliable investment in the future of your company. Warranty Terms
2-3 Day Free Shipping
Packed Ready to Ship
24/7 Expert Support
Return within 30-Days
IQElectro LLC BBB Business Review
IQElectro is Not an authorized distributor for Allen-Bradley
Original Manufacturer's Warranty Not Covered, This Product is SURPLUS.

Product Description P/N: 2711P-T6C5D8

Description / Specifications

Description

The Allen-Bradley 2711P-T6C5D8 is a PanelView Plus 6 600 operator terminal designed for machine-level monitoring and control. It features a 5.7-inch color touchscreen display, powered by an external 18–30 VDC supply, with integrated RS-232 and dual USB ports for connectivity.





Technical Specifications

Brand Allen-Bradley
Manufacturer Rockwell Automation
Part Number 2711P-T6C5D8
Input Voltage range 18-30VDC
Integrated ports One (1) RS-232, Two (2) USB
Internal memory 256 MB RAM, 512 MB nonvolatile memory (approx. 79 MB free user memory)
Touch Analog Resistive
Resolution 320 x 240, 18-bit color
Display Area 115 x 86 mm (4.5 x 3.4 in.)
Display Type Color active-matrix TFT
Operator Input Touch
Product Type PanelView Plus 6 600 Operator Terminals
Product Family PanelView Plus 6 Operator Terminals
Display Size 5.7 in.
Backlight White LED, not replaceable; 25,000 hours min at 25 °C (77 °F)
Product Line Panelview 6 Plus
Input Type Touchscreen
Communication RS-232
Input Power 18-30 VDC
Memory 256 MB RAM
Communication Cable 2711-NC13
Shipping Dimensions 14 x 11 x 8 in
Series PanelView Plus 600





Information About 2711P-T6C5D8

The 2711P-T6C5D8 is part of the Allen-Bradley PanelView Plus 6 family, built to deliver reliable operator interface functions in industrial environments. It uses a 5.7-inch color TFT display with 320 × 240 resolution and 18-bit color depth, providing clear visualization of control data. The terminal includes an analog resistive touchscreen for user input, backed by a durable white LED backlight rated for 25,000 hours at 25 °C. It comes with 256 MB RAM and 512 MB of nonvolatile memory (approximately 79 MB free for user applications), supporting application storage and runtime performance. For connectivity, it offers one RS-232 port and two USB ports, allowing flexible communication with controllers and external devices. Designed for compact operator interface applications, this model is classified as end-of-life but remains widely used in established automation systems.

Key Features:

  • Display: 5.7-inch color TFT active-matrix display with 320 × 240 resolution and 18-bit color depth.
  • Touchscreen: Analog resistive input for intuitive operator control and navigation.
  • Backlight: White LED backlight rated for 25,000 hours minimum at 25 °C, non-replaceable.
  • Memory: 256 MB RAM and 512 MB nonvolatile memory, with ~79 MB available for user applications.
  • Ports: Integrated RS-232 port and two USB ports for controller and peripheral connectivity.
  • Power Supply: Operates on an external 18–30 VDC power source.
  • Display Area: Active viewing area of 115 × 86 mm (4.5 × 3.4 in.) for clear visualization.
  • Lifecycle: Classified as end-of-life but still in use in many automation systems.

The 2711P-T6C5D8 delivers the reliability and precision required for operator interface tasks in industrial automation systems.




Manufacturer information

Allen-Bradley, a brand of Rockwell Automation, specializes in manufacturing industrial automation equipment. The product range includes programmable logic controllers (PLCs), motion control systems, safety devices, motor control equipment, automation software, and HMI panels. Allen-Bradley products are known for their reliability and integration with other systems.

Frequently Asked Questions about 2711P-T6C5D8
Question: Is the 2711P-T6C5D8 PanelView Plus 6 still in production?
Date Update:29/05/2025
Answer:

No, the 2711P-T6C5D8 was officially discontinued by Rockwell Automation on September 30, 2021. There is no planned direct replacement from Rockwell Automation.

Question: What are the key features and specifications of the 2711P-T6C5D8?
Date Update:29/05/2025
Answer:
  • Display: 5.7-inch color TFT touchscreen with a resolution of 320 x 240 pixels.
  • Touch Technology: Analog resistive.
  • Memory: 256 MB RAM and 512 MB nonvolatile memory (approximately 79 MB free user memory).
  • Operating System: Windows CE 6.0 with extended features.
  • Communication Ports: One RS-232 port, one USB host port, and one USB device port.
  • Power Supply: 18–30V DC (24V DC nominal).
  • Environmental Ratings: NEMA Type 12, 13, 4X (Indoor use only), IP54, IP65.
  • Operating Temperature: 0°C to 55°C (32°F to 131°F).
  • Dimensions: 152 x 185 x 68 mm (5.98 x 7.28 x 2.68 in).
  • Weight: Approximately 594 g.
Question: What software is compatible with the 2711P-T6C5D8?
Date Update:29/05/2025
Answer:

The 2711P-T6C5D8 is compatible with FactoryTalk® View Studio Machine Edition software, version 6.0 or later. It comes preloaded with FactoryTalk View Machine Edition Station runtime, version 6.0 or later. Note that FactoryTalk ViewPoint software is not supported on the 400 and 600 terminals.

Question: What are the power requirements and consumption for the 2711P-T6C5D8?
Date Update:29/05/2025
Answer:
  • Input Voltage Range: 18–30V DC (24V DC nominal).
  • Power Consumption: Typical: 9 W (0.375A @ 24V DC); Maximum: 15 W (0.6A @ 24V DC).
Question: What are the available communication interfaces on the 2711P-T6C5D8?
Date Update:29/05/2025
Answer:

The 2711P-T6C5D8 includes the following communication interfaces:

  • Serial Port: One RS-232 port.
  • USB Ports: One USB host port and one USB device port.
  • Note: This model does not include Ethernet connectivity.
IQElectro is not an authorized distributor.
IQElectro LLC (IQElectro) is NOT an Authorized Distributor or in any way affiliated with Rockwell Automation, Siemens, or any other Manufacturers. IQElectro is NOT an Authorized Dealer of this product. The product may be of older version, date codes, or design than that available from authorized dealers. As IQElectro is not an authorized dealer of this product, the Original Manufacturer's Warranty and Support DO NOT apply. IQElectro sells SURPLUS only and DOES NOT SELL SOFTWARE or FIRMWARE licenses For more detailed information, please refer to the full version of our disclaimer policy Disclaimer Policy.
Description / Specifications

Description

The Allen-Bradley 2711P-T6C5D8 is a PanelView Plus 6 600 operator terminal designed for machine-level monitoring and control. It features a 5.7-inch color touchscreen display, powered by an external 18–30 VDC supply, with integrated RS-232 and dual USB ports for connectivity.





Technical Specifications

Brand Allen-Bradley
Manufacturer Rockwell Automation
Part Number 2711P-T6C5D8
Input Voltage range 18-30VDC
Integrated ports One (1) RS-232, Two (2) USB
Internal memory 256 MB RAM, 512 MB nonvolatile memory (approx. 79 MB free user memory)
Touch Analog Resistive
Resolution 320 x 240, 18-bit color
Display Area 115 x 86 mm (4.5 x 3.4 in.)
Display Type Color active-matrix TFT
Operator Input Touch
Product Type PanelView Plus 6 600 Operator Terminals
Product Family PanelView Plus 6 Operator Terminals
Display Size 5.7 in.
Backlight White LED, not replaceable; 25,000 hours min at 25 °C (77 °F)
Product Line Panelview 6 Plus
Input Type Touchscreen
Communication RS-232
Input Power 18-30 VDC
Memory 256 MB RAM
Communication Cable 2711-NC13
Shipping Dimensions 14 x 11 x 8 in
Series PanelView Plus 600





Information About 2711P-T6C5D8

The 2711P-T6C5D8 is part of the Allen-Bradley PanelView Plus 6 family, built to deliver reliable operator interface functions in industrial environments. It uses a 5.7-inch color TFT display with 320 × 240 resolution and 18-bit color depth, providing clear visualization of control data. The terminal includes an analog resistive touchscreen for user input, backed by a durable white LED backlight rated for 25,000 hours at 25 °C. It comes with 256 MB RAM and 512 MB of nonvolatile memory (approximately 79 MB free for user applications), supporting application storage and runtime performance. For connectivity, it offers one RS-232 port and two USB ports, allowing flexible communication with controllers and external devices. Designed for compact operator interface applications, this model is classified as end-of-life but remains widely used in established automation systems.

Key Features:

  • Display: 5.7-inch color TFT active-matrix display with 320 × 240 resolution and 18-bit color depth.
  • Touchscreen: Analog resistive input for intuitive operator control and navigation.
  • Backlight: White LED backlight rated for 25,000 hours minimum at 25 °C, non-replaceable.
  • Memory: 256 MB RAM and 512 MB nonvolatile memory, with ~79 MB available for user applications.
  • Ports: Integrated RS-232 port and two USB ports for controller and peripheral connectivity.
  • Power Supply: Operates on an external 18–30 VDC power source.
  • Display Area: Active viewing area of 115 × 86 mm (4.5 × 3.4 in.) for clear visualization.
  • Lifecycle: Classified as end-of-life but still in use in many automation systems.

The 2711P-T6C5D8 delivers the reliability and precision required for operator interface tasks in industrial automation systems.




Manufacturer information

Allen-Bradley, a brand of Rockwell Automation, specializes in manufacturing industrial automation equipment. The product range includes programmable logic controllers (PLCs), motion control systems, safety devices, motor control equipment, automation software, and HMI panels. Allen-Bradley products are known for their reliability and integration with other systems.
