2725260 | Phoenix Contact Termination Board
- Regular price
- $799.00
- Sale price
- $799.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 2725260
Description
The Phoenix Contact 2725260 TERMINATION BOARD IN PCI FORMAT, also known as IBS PCI SC/I-T, is a termination board designed for integration into PCI master controller systems. It facilitates electrical isolation and serves as a pivotal component for PCI-based industrial control setups.
Technical Specifications
|
Part Number |
IBS PCI SC/I-T |
|
Manufacturer |
Phoenix Contact |
|
Category |
PLCs/Machine Control |
|
Subcategory |
VDC Logic I/O Module Designation: SC, HF, PF, BSA, FAIL |
|
Monitored function |
INTERBUS |
|
Optical representation |
Status display via LED Local diagnostics: SC, HF, PF, BSA, FAIL INTERBUS Status display via LED |
|
Transmission medium |
Copper |
|
Maximum power dissipation |
Max. 3.5 W |
|
Supply voltage |
5 V DC |
|
Supply voltage range |
± 5% (including ripple) |
|
Power supply connection |
Via PCI bus |
|
Typical current consumption |
0.7 A |
|
Input name |
Digital inputs |
|
Number of inputs |
6 (EN 61131-2 type 1) |
|
Connection technology |
FLK cable connector (14-pos.) |
|
Nominal input voltage UIN |
24 V DC |
|
Output name |
Digital outputs |
|
Connection technology |
FLK cable connector (14-pos.) |
|
Number of outputs |
2 |
|
Output voltage |
24 V DC |
|
Maximum output current per channel |
0.5 A |
|
Degree of protection |
IP20 (Must be installed in a device with IP20) |
|
Ambient temperature (operation) |
0 °C ... 55 °C (acc. to EN 60204-1) |
|
Ambient temperature (storage/transport) |
-25 °C ... 75 °C (acc. to EN 60204-1) |
|
Permissible humidity (operation) |
75% (on average, 85% infrequently, non-condensing) |
|
Air pressure (operation) |
860 hPa ... 1080 hPa (up to 2000 m above sea level) |
|
Air pressure (storage/transport) |
660 hPa ... 1080 hPa (up to 3000 m above sea level) |
Information About 2725260
The Phoenix Contact 2725260 TERMINATION BOARD IN PCI FORMAT, designated as IBS PCI SC/I-T, serves as a termination board primarily intended for deployment within PCI master controller configurations. This board offers electrical isolation, enhancing system reliability and mitigating potential issues arising from electrical noise or ground loops.
Designed to adhere to PCI standards, this termination board ensures compatibility with various industrial control setups employing PCI-based master controllers. The integration of electrical isolation safeguards against potential disruptions in signal integrity, maintaining stable communication within the system.
The termination board, marked as 2725260, is engineered with meticulous attention to detail to meet the stringent requirements of industrial applications. It is designed to function seamlessly within PCI-based systems, providing a reliable interface for communication between different components.
Manufacturer information
Phoenix Contact is a global market leader and innovator in the electrical engineering and automation sectors. Founded in 1923 the family-owned company from Blomberg, Germany, now owns an international distribution network providing guaranteed proximity to its customers. Phoenix Contact offers innovative products and solutions around industrial connection technology, automation, interface-systems and surge protection. The product range includes sensors, controllers, modular terminal blocks, splash-proof machinery connectors, wireless Ethernet products for up-to-date control cabinets, and custom solutions for various applications.
