2901428 | Phoenix Contact Psr-Scp-230Uc/EsaM4/3X1/1X2/B Safety Relay 230Vac/Dc Sil3 Ple Emergency Stop
- Regular price
- $339.00
- Sale price
- $339.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 2901428
Description
The Phoenix Contact 2901428 is a safety relay designed for emergency stop and safety door monitoring applications requiring SIL 3 or PL e performance levels. Operating at 230 V AC/DC, it provides reliable safety logic processing with multiple enabling paths for high-integrity machine protection.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Phoenix Contact |
| Part Number | 2901428 |
| Category | Safety Systems |
| Subcategory | Safety Relay |
| Series | PSR CLASSIC Series |
| Type | Safety Relay for E-Stop & Safety Door Monitoring |
| Input Voltage | 230 V AC/DC |
| Contact Form | 4PST (3NO / 1NC) |
| Contact Material | AgSnO + 0.2 m Au |
| Contact Rating | 6 A Max |
| Switching Voltage | 250 VAC / 250 VDC Max |
| Coil Current | 22 mA |
| Coil Power | 5.06 W |
| Coil Resistance | 10.46 kΩ |
| Operate Time | 40 ms |
| Release Time | 150 ms |
| Mounting Type | DIN Rail |
| Termination Style | Screw Terminal |
| Features | Lighted Indicator |
| Operating Temperature | –25°C to +55°C |
Information About 2901428
The Phoenix Contact 2901428 PSR-SCP-230UC/ESAM4/3X1/1X2/B is a high-integrity safety relay engineered for emergency stop and safety door monitoring applications up to SIL 3, Cat. 4, and PL e. Designed for one- or two-channel operation, it offers three enabling current paths and a robust 4PST contact configuration, making it suitable for demanding machine safety architectures. Its 230 V AC/DC universal coil ensures compatibility with common industrial power systems, while screw-terminal plug-in blocks simplify installation and wiring. The relay integrates into PSR CLASSIC safety circuits and provides clear visual indication through its lighted status display. Built for harsh industrial environments, it maintains reliable performance across a wide temperature range, supporting the safety integrity requirements of modern automated machinery.
Key Features:
- SIL 3 / Cat. 4 / PL e Safety Compliance: Designed to meet the highest levels of functional safety for emergency stop and safety door applications.
- Universal 230 V AC/DC Coil: Supports flexible power integration in diverse industrial control systems.
- 4PST Output Configuration: Provides three NO enabling paths and one NC monitoring contact for robust safety circuit design.
- Fast Response Performance: Operate and release times of 40 ms and 150 ms support rapid safety function execution.
- AgSnO + Gold-Plated Contacts: Ensures long electrical life, corrosion resistance, and reliable low-level switching.
- DIN Rail Mounting: Enables simple panel installation and modular safety system expansion.
- Integrated Status Indicator: Illuminated display provides immediate feedback on relay operating state.
- Rugged Industrial Construction: Operates from –25°C to +55°C and withstands challenging plant-floor environments.
The 2901428 delivers the reliability and precision required for high-integrity emergency stop and safety door monitoring in industrial automation systems.
