2938963 | Phoenix Contact | Redundancy Module
2938963 | Phoenix Contact | Redundancy Module
Part #: 2938963 Manufactured by: Phoenix Contact

2938963 | Phoenix Contact | Redundancy Module

Regular price
$145.00
Sale price
$145.00
Regular price
Never Used Surplus
4 in Stock
Shipping calculated at checkout.
Product Overview
The Phoenix Contact 2938963 Redundancy Module, designated as QUINT-DIODE/40, is a power supply accessory specifically engi...  Read more
We accept:
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Meta Pay
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Venmo
  • Visa
IQElectro LLC BBB Business Review
warranty
Product comes with IQElectro 2-Year Warranty
Warranty for item #: 2938963
IQElectro offers a complimentary 2-year warranty on all our products. This ensures that every purchase you make from IQElectro is a reliable and trustworthy investment for the future of your company. Warranty Terms
IQElectro is NOT an authorized distributor for Phoenix Contact
Original Manufacturer's Warranty Not Covered, This Product is SURPLUS.
2938963 | Phoenix Contact | Redundancy Module
    2938963 | Phoenix Contact | Redundancy Module
2938963 | Phoenix Contact | Redundancy Module
Return/Exchange within 30-Days.
If any product is damaged upon delivery, you may request an Exchange or Refund within 30 days of receiving your order.
2-3 Day Free Shipping
IQElectro provides free shipping within 2-3 days from the moment the order is placed on our website.

Product Description P/N: 2938963

Description / Specifications

Description

The Phoenix Contact 2938963 Redundancy Module, specifically the QUINT-DIODE/40, is a power supply accessory designed for three-phase applications. This redundancy module is engineered to enhance the reliability and stability of power supply systems. The product code for this module is 2938963, and it operates within the QUINT series. It plays a crucial role in optimizing the performance and efficiency of power supply configurations by providing redundancy support. The QUINT-DIODE/40 redundancy module is designed to meet the demanding requirements of industrial power supply setups, ensuring seamless operation and enhanced reliability in three-phase applications.



Technical Specifications





Part #

QUINT-DIODE/40

Manufacturer

PHOENIX CONTACT

Category

Power Supplies

Subcategory

Power Supply

Input voltage

24 V DC

Nominal input voltage range

24 V DC

Input voltage range

0 V DC ... 30 V DC

Voltage type of supply voltage

DC

Reverse polarity protection

< 60 V (yes)

Nominal input current (IN)

2x 20 A

Transient surge protection

Transil diode

Voltage drop, input/output

0.5 V

Efficiency

> 97 %

Nominal output voltage

24 V DC

Nominal output current (IN)

40 A

Power loss nominal load max.

20 W

Connection in series

No

Connection method

Screw connection

Conductor cross section, rigid (min)

0.5 mm²

Conductor cross section, rigid (max)

16 mm²

Conductor cross section, flexible (min)

0.5 mm²

Conductor cross section, flexible (max)

10 mm²

Conductor cross section AWG (min)

20

Conductor cross section AWG (max)

6

Stripping length

10 mm

Screw thread

M4

Insulation voltage output / PE

1 kV

Insulation voltage input / PE

1 kV

Insulation voltage input, output / housing

1 kV

Housing material

Metal

Type of housing

AIMg (hood), GD-ZnAICu (cooling unit)

Degree of protection

IP20

Ambient temperature (operation)

-25 °C ... 70 °C (> 60 °C derating, -25 ... 60°C)

Ambient temperature (storage/transport)

-40 °C ... 85 °C

Max. permissible relative humidity (operation)

≤ 95 % (at 25˽°C, non-condensing)





Information About 2938963


The Phoenix Contact 2938963 redundancy module, designated as QUINT-DIODE/40, is a power supply accessory engineered to ensure robust and reliable operation in three-phase electrical systems. This redundancy module is designed to enhance the resilience and efficiency of power supply systems by offering seamless redundancy capabilities.

As a vital component in power supply systems, the QUINT-DIODE/40 redundancy module plays a critical role in safeguarding against power disruptions and failures. By integrating this module into the power supply architecture, users can mitigate the risk of downtime and maintain uninterrupted operation in industrial environments.

The QUINT-DIODE/40 redundancy module is specifically engineered for three-phase applications, providing a robust solution for demanding industrial settings. With its advanced design and construction, this module offers superior performance and durability, meeting the stringent requirements of modern industrial automation systems.

One of the key features of the QUINT-DIODE/40 redundancy module is its ability to ensure seamless power transfer and distribution in three-phase systems. By employing sophisticated diode technology, this module effectively manages the flow of electrical currents, optimizing power distribution and enhancing system reliability.

The redundancy module is equipped with comprehensive protection mechanisms to safeguard against voltage fluctuations, short circuits, and other electrical anomalies. This ensures the integrity of the power supply system and protects connected equipment from potential damage or malfunctions.





Manufacturer information

Phoenix Contact is a global market leader and innovator in the electrical engineering and automation sectors. Founded in 1923 the family-owned company from Blomberg, Germany, now owns an international distribution network providing guaranteed proximity to its customers. Phoenix Contact offers innovative products and solutions around industrial connection technology, automation, interface-systems and surge protection. The product range includes sensors, controllers, modular terminal blocks, splash-proof machinery connectors, wireless Ethernet products for up-to-date control cabinets, and custom solutions for various applications.
