323D-10AW-R | Edwards Signaling 10-Inch Single-Stroke Fire Alarm Bell 24VDC Red
- Regular price
- $505.00
- Sale price
- $505.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 323D-10AW-R
Description
The Edwards Signaling 323D-10AW-R Fire Alarm Bell is a 10-inch single-stroke audible signaling device designed for use in fire alarm and general signaling systems. Operating at 20–24 VDC and finished in red, it delivers a clear, resonant tone suitable for alerting personnel in industrial, commercial, and institutional environments.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Edwards Signaling |
| Category | Fire Alarm and Safety Devices |
| Part Number | 323D-10AW-R |
| Subcategory | Fire Alarm Bells |
| Series | 323D |
| Type | Single-Stroke Fire Alarm Bell |
| Operation Type | Single-stroke mechanical |
| Nominal Voltage | 24 VDC |
| Operating Voltage Range | 20–24 VDC |
| Current Rating | 0.33 A |
| Bell Diameter | 10 inches |
| Sound Type | Single resonant strike |
| Mounting Type | Wall mount |
| Material | Heavy-duty metal construction |
| Color | Red |
| Approvals | UL Listed, FM Approved |
| Power Source | DC power from fire alarm circuit |
| Ambient Temperature | 32°F to 120°F (0°C to 49°C) typical |
| Enclosure Type | Indoor rated |
| Connection Type | Hardwired |
| Application | Fire alarm, evacuation, general signaling |
| Weight | 6.92 lb (3.14 kg) |
Information About 323D-10AW-R
The 323D-10AW-R is part of the Edwards 323D Series of high-quality audible signaling bells built for reliable fire and evacuation notification. Constructed with durable materials and precision engineering, this bell produces a strong, single-strike tone for unmistakable alarm signaling. It operates on 24 VDC nominal voltage with a current draw of 0.33 A, providing efficient performance while maintaining compatibility with standard fire alarm control panels. The 10-inch gong ensures broad sound coverage, and the rugged housing is suited for both new installations and system retrofits. UL and FM approvals ensure compliance with safety and performance standards.
Key Features:
- Single-Stroke Operation: Produces one clear, resonant strike per activation for unmistakable alerts.
- 10-Inch Diameter Bell: Provides high sound output and excellent coverage in large spaces.
- 24 VDC Operation: Compatible with most fire alarm and signaling systems.
- Low Current Draw: Efficient 0.33 A operation reduces system load.
- Durable Construction: Built for reliable service in commercial and industrial environments.
- Easy Installation: Wall-mountable design for standard electrical boxes or mounting plates.
- Red Finish: Provides clear visual identification for fire alarm use.
- UL and FM Approved: Meets key safety and reliability standards for alarm devices.
The 323D-10AW-R delivers the reliability and precision required for dependable audible notification in fire alarm and emergency systems.
