3G2C4-SI022 | Omron 3G2 Expansion I/O Rack 200–240VAC
- Regular price
- $1,289.00
- Sale price
- $1,289.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: 3G2C4-SI022
Description
The Omron 3G2C4-SI022 is an expansion input/output rack designed for mounting I/O units within 3G2 programmable controller systems. It operates on 200–240 VAC at 50/60 Hz with a power consumption of 35 VA. This rack provides a structured platform for secure module installation and reliable signal distribution in industrial automation panels.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Omron |
| Category | Industrial Automation |
| Part Number | 3G2C4-SI022 |
| Subcategory | PLC Expansion Racks |
| Product Line | 3G2 |
| Product Type | Expansion Input/Output Rack |
| Rated Supply Voltage | 200–240 VAC |
| Input Frequency | 50–60 Hz |
| Power Consumption | 35 VA |
| Termination Style | Screw Terminal |
| Status Indicators | LED Indicators |
| Ambient Operating Temperature | 0 to 50°C |
| Storage Temperature | -20 to 65°C |
| Humidity Tolerance | 35–80% RH (Non-condensing) |
| Vibration Resistance | Up to 10 G (X, Y, Z axes) |
| Insulation Resistance | 5 MΩ at 500 VDC |
| Noise Immunity | 1,000 Vp-p |
| Protection Class | IP30 |
| Application | Mounting of PLC Input/Output Units |
| Weight | 2.06 lbs (0.94 kg) |
Information About 3G2C4-SI022
The 3G2C4-SI022 is an expansion I/O rack developed for Omron 3G2 Series programmable controllers. It is used to mount and interconnect input and output units, supporting system expansion in modular PLC configurations. The rack features screw terminal connections and LED status indicators for clear operational monitoring. Designed for 200–240 VAC supply operation, it meets industrial standards for insulation resistance, vibration tolerance, and noise immunity, making it suitable for stable performance in control cabinet environments.
Key Features:
- Expansion I/O Rack Design: Supports mounting of additional input and output modules.
- 200–240 VAC Operation: Rated for standard industrial AC power systems.
- 35 VA Power Consumption: Efficient power usage for rack operation.
- LED Status Indicators: Provides visual system and operational status feedback.
- Screw Terminal Termination: Ensures secure wiring connections.
- Industrial Environmental Tolerance: Operates within 0 to 50°C and 35–80% non-condensing humidity.
- High Noise Immunity: Rated up to 1,000 Vp-p for electrical noise resistance.
- IP30 Protection Class: Suitable for protected control panel installations.
The 3G2C4-SI022 delivers the reliability and precision required for secure I/O module mounting and expansion in programmable controller systems.
Description
The Omron 3G2C4-SI022 is an expansion input/output rack designed for mounting I/O units within 3G2 programmable controller systems. It operates on 200–240 VAC at 50/60 Hz with a power consumption of 35 VA. This rack provides a structured platform for secure module installation and reliable signal distribution in industrial automation panels.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Omron |
| Category | Industrial Automation |
| Part Number | 3G2C4-SI022 |
| Subcategory | PLC Expansion Racks |
| Product Line | 3G2 |
| Product Type | Expansion Input/Output Rack |
| Rated Supply Voltage | 200–240 VAC |
| Input Frequency | 50–60 Hz |
| Power Consumption | 35 VA |
| Termination Style | Screw Terminal |
| Status Indicators | LED Indicators |
| Ambient Operating Temperature | 0 to 50°C |
| Storage Temperature | -20 to 65°C |
| Humidity Tolerance | 35–80% RH (Non-condensing) |
| Vibration Resistance | Up to 10 G (X, Y, Z axes) |
| Insulation Resistance | 5 MΩ at 500 VDC |
| Noise Immunity | 1,000 Vp-p |
| Protection Class | IP30 |
| Application | Mounting of PLC Input/Output Units |
| Weight | 2.06 lbs (0.94 kg) |
Information About 3G2C4-SI022
The 3G2C4-SI022 is an expansion I/O rack developed for Omron 3G2 Series programmable controllers. It is used to mount and interconnect input and output units, supporting system expansion in modular PLC configurations. The rack features screw terminal connections and LED status indicators for clear operational monitoring. Designed for 200–240 VAC supply operation, it meets industrial standards for insulation resistance, vibration tolerance, and noise immunity, making it suitable for stable performance in control cabinet environments.
Key Features:
- Expansion I/O Rack Design: Supports mounting of additional input and output modules.
- 200–240 VAC Operation: Rated for standard industrial AC power systems.
- 35 VA Power Consumption: Efficient power usage for rack operation.
- LED Status Indicators: Provides visual system and operational status feedback.
- Screw Terminal Termination: Ensures secure wiring connections.
- Industrial Environmental Tolerance: Operates within 0 to 50°C and 35–80% non-condensing humidity.
- High Noise Immunity: Rated up to 1,000 Vp-p for electrical noise resistance.
- IP30 Protection Class: Suitable for protected control panel installations.
The 3G2C4-SI022 delivers the reliability and precision required for secure I/O module mounting and expansion in programmable controller systems.
