3G3JX-A4015-EF | Omron JX Series 1.5 kW 3-Phase 400 V Frequency Inverter Drive
- Regular price
- $869.00
- Sale price
- $869.00
- Regular price
-
$0.00
Couldn't load pickup availability
Do you need help?
Product Description P/N: 3G3JX-A4015-EF
Description
The Omron 3G3JX-A4015-EF Frequency Inverter is a compact, high-performance drive designed for precise control of 1.5 kW three-phase motors. Operating at 380–480 V AC, it provides smooth motor acceleration, speed regulation, and braking with reliable protection features. Ideal for general-purpose automation, it delivers dependable and efficient motor control across a wide frequency range up to 400 Hz.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Omron |
| Category | Industrial Automation and Controls |
| Part Number | 3G3JX-A4015-EF |
| Subcategory | Inverters / Variable Frequency Drives |
| Series | JX Series |
| Type | AC Frequency Inverter / Variable Speed Drive |
| Motor Power Rating | 1.5 kW |
| Rated Input Voltage | 3 × 380–480 V AC |
| Rated Output Voltage | 3 × 380–480 V AC |
| Rated Output Current | 3.8 A |
| Output Frequency Range | 0.5–400 Hz |
| Control Method | V/f Control |
| Analog Inputs | 1 (0–10 V, 4–20 mA, 0–20 mA) |
| Analog Outputs | 1 (0–10 V) |
| Digital Inputs | 6 programmable |
| Digital Outputs | 5 programmable |
| Relay Output | 1 (3 A / 250 V AC or 24 V DC selectable) |
| Acceleration / Deceleration Time | 0.01–3000 s / 0.01–3000 s |
| Programming Interface | Built-in Keypad and Potentiometer |
| Voltage Output | 0–10 V (analog signal) |
| Starting Torque | 150% at 3 Hz |
| Protection Functions | OPP (Overload), OVP (Overvoltage), OTP (Overheat), SCP (Short Circuit), BOP (Voltage Drop) |
| Mounting Type | Wall Mount |
| Electrical Connection | Screw Terminals |
| Enclosure Rating | IP20 |
| Operating Temperature Range | -10°C to +50°C |
| Storage Temperature Range | -20°C to +60°C |
| Cooling Method | Forced Air (integrated fan) |
| Additional Functions | PID Control, programmable I/O, motor braking |
| Display Type | LED Display |
| Compliance | CE, UL, RoHS Compliant |
| Product Status | Discontinued by Manufacturer |
| Dimensions | Approx. 68 × 128 × 128 mm (W × H × D) |
| Weight | Approx. 1.7 kg (3.75 lb) |
Information About 3G3JX-A4015-EF
The 3G3JX-A4015-EF is part of Omron’s JX Series of general-purpose inverters, engineered for versatility, efficiency, and ease of use in industrial motor control applications. Designed for three-phase 400 V AC systems, this inverter supports a maximum motor output of 1.5 kW and a rated current of 3.8 A. It provides both analog (0–10 V, 4–20 mA, 0–20 mA) and digital input control, allowing integration with automation systems, PLCs, or manual operation through its built-in keypad and potentiometer. Advanced protection features, including overload, overvoltage, short-circuit, and thermal safeguards, ensure stable performance and extended service life in demanding environments.
Key Features:
- 1.5 kW Motor Capacity: Designed for efficient control of three-phase 400 V motors.
- Wide Output Frequency Range: Adjustable 0.5–400 Hz for versatile motion applications.
- Analog and Digital Inputs: Supports 0–10 V, 4–20 mA, and 0–20 mA control signals.
- Integrated Programming Interface: Built-in keypad and potentiometer simplify setup.
- Comprehensive Protection System: Includes OVP, OPP, OTP, SCP, and BOP protection functions.
- Programmable I/O: Six inputs, multiple digital and analog outputs, and relay configuration options.
- Compact Wall-Mount Enclosure: IP20-rated design suitable for panel installations.
- Omron Reliability: Proven durability and consistent performance in industrial use.
The 3G3JX-A4015-EF delivers the reliability and precision required for variable speed control, energy efficiency, and safe motor operation in automation systems.
