3RH1140-1AK60 | Siemens Control Relay IEC SIRIUS Electrically Held 120 VAC
- Regular price
- $155.00
- Sale price
- $155.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 3RH1140-1AK60
Description
The Siemens 3RH1140-1AK60 is a compact and reliable IEC control relay from the SIRIUS series, engineered for controlling and signaling switching tasks. It is electrically held and operates on 110 V AC at 50 Hz or 120 V AC at 60 Hz, ideal for general industrial control applications.
Technical Specifications
|
Condition |
New/Never Used Surplus |
|---|---|
| Brand | Siemens |
| Category |
Relays
|
| Part Number | 3RH1140-1AK60 |
| Subcatecory |
Permissive Relays
|
| Series | SIRIUS |
| Type |
Control Relay (Electrically Held) |
| Rated Control Voltage | 110 V AC (50 Hz), 120 V AC (60 Hz) |
| Contact Configuration |
4 NO |
| Size |
S00 |
| Mounting Type |
Screw Terminal |
| Rated Insulation Voltage |
690 V |
| Surge Withstand Voltage |
6 kV |
| Identification Code |
40 E |
| Dimensions (H x W x D) |
1.969 x 2.50 x 3.031 |
| Package size unit of measure |
Inch |
| Weight |
0.452 lb |
Information About 3RH1140-1AK60
The 3RH1140-1AK60 is a size S00 contactor relay designed with four normally open (4 NO) contacts and screw terminals. It supports high durability and electrical performance, offering an insulation voltage of 690V and surge resistance up to 6 kV. Though this product has been phased out, its preferred successor is 3RH2140-1AK60, a part of the enhanced SIRIUS 3RH2 series.
Key Features:
-
High Operating Voltage: Rated insulation voltage up to 690 V, ensuring compatibility with a broad range of control systems.
-
Reliable Switching Capacity: Handles up to 10 A at AC-12 and 6 A at 230 V under AC-15 conditions.
-
Control Supply Versatility: Supports 110 V at 50 Hz and 120 V at 60 Hz, making it adaptable to international standards.
-
Compact Size S00: Designed for space-saving installations, ideal for control cabinets and automation panels.
-
SIRIUS Series Compatibility: Seamless integration into SIRIUS motor control and protection systems with successor continuity.
The 3RH1140-1AK60 offers dependable control performance in industrial applications and is succeeded by the enhanced 3RH2140-1AK60 model.
