Product Description P/N: 3RT1044-1AK60
Description
The Siemens Sirius 3RT1044-1AK60 is a 3-phase IEC rated contactor used for the control of electric motors. It is rated 25 HP at 230V and 50 HP at 460V.
Technical Specifications
| Brand | SIEMENS |
| Part Number | 3RT1044-1AK60 |
| Category | Contactors & Starters |
| Subcategory | Contactor |
| Contact Current Rating | 65 A |
| Control Voltage | 120 VAC |
| Current Rating | 65 A |
| Depth | 0.118" (3mm) |
| Function | IEC Contactor |
| Horsepower Rating | 60 HP |
| Horsepower, Max, 1 Phase, at 115 V | 5 |
| Horsepower, Max, 1 Phase, at 208 V | 10 |
| Horsepower, Max, 1 Phase, at 230 V | 15 |
| Horsepower, Max, 3 Phase, at 208 V | 20 |
| Horsepower, Max, 3 Phase, at 230 V | 25 |
| Horsepower, Max, 3 Phase, at 460 V | 50 |
| Horsepower, Max, 3 Phase, at 575 V | 60 |
| Length | 5.748" (146mm) |
| Maximum Operating Temperature | 60 °C |
| Minimum Operating Temperature | -25 °C |
| Mounting Type | DIN Rail Mounted |
| Number of Poles | 3 |
| Power Rating | 30 kW W |
| Primary Type | IEC Contactor |
| Series | 3RT Series |
| Size | S3 in |
| Standards | CAC ; CE Approved ; CSA Certified ; GOST Certified ; UL Recognized |
| Temperature Operating Range | -25 to 60 C |
| Terminal Type | Screw Terminal |
| Termination | Screw |
| Type | Contactor |
| Voltage Rating | 400 VAC |
| Width | 2.756" (70mm) |
Information About 3RT1044-1AK60
Siemens Sirius 3-Pole 3RT Series IEC Contactor has coil voltage rating of 110/120-Volt AC at 50/60-Hz and current rating of 90/50-Amps. It has screw terminal connection and supports screw/snap-on mounting. Contactor has power rating of 5 hp at 115-Volts, 15 hp at 230-Volts, 20 at 200-Volts,25 hp at 230-Volts, 50 hp at 460-Volts and 60 hp at 575-Volts. It has 3 NO contact configuration. NEMA S3 rated contactor accepts two 10 - 1/0-AWG main, two 20 - 16-AWG, two 18 - 14-AWG, one 12-AWG size auxiliary wires for optimal conductivity. It offers IP00-degree of protection from harsh environments. Contactor withstands temperature rating of -25 to 50 deg C. Contactor is UL listed, CSA/CE/CCC certified and meets EAC standards.
Has 10-Amp auxiliary fuse gL/gG and 250-, 125-Amp main fuse gL/gG fuse link design
The 4-point AC coil allows you to wire on top, bottom or diagonally
Direct mount 3RU11 overload relays generate starters
Manufacturer information
Siemens: A renowned global manufacturer, leading in technology, engineering, and innovation across diverse sectors for a sustainable future.
