3RV1031-4EA10 | Siemens Manual Motor Protector/Circuit Breaker
- Regular price
- $229.00
- Sale price
- $229.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 3RV1031-4EA10
Description
The Siemens 3RV1031-4EA10 SIRIUS Manual Motor Protector/Circuit Breaker is designed as part of the SIRIUS 3RV1 series for motor protection. It functions as a circuit breaker with a motor protection CLASS 10 rating. This device operates within a current setting range of 22-32A and features an instantaneous short-circuit release (N-release) with a capacity of 416A. It is configured as a 3-pole circuit breaker with a maximum voltage rating of 575V AC. The device is sized as S2 and utilizes screw connections. It offers standard switching capacity and does not include an auxiliary switch.
Technical Specifications
|
Part # |
3RV1031-4EA10 |
|
Manufacturer |
SIEMENS |
|
Category |
Circuit Breaker |
|
Subcategory |
Molded Case Circuit Breaker |
|
Auxiliary switch |
Yes |
|
Power loss [W] total typical |
15 W |
|
Surge voltage resistance rated value |
6,000 V |
|
IP Rating |
IP20 (on the front) |
|
Number of poles for main current circuit |
3 |
|
Adjustable pick-up value current |
22 ... 32 A |
|
Rated voltage |
690 V |
|
Rated value maximum |
690 V |
|
Rated value at 400 V |
32 A |
|
Rated short-circuit breaking capacity at 240V |
100 kA |
|
Rated short-circuit breaking capacity at 400V |
50 kA |
|
Rated short-circuit breaking capacity at 500V |
10 kA |
|
Rated short-circuit breaking capacity at 690V |
4 kA |
|
Mounting position |
Any |
|
Mounting type |
Screw and snap-on mounting onto 35 mm standard mounting rail according to DIN EN 50022 |
|
Height |
140 mm |
|
Width |
55 mm |
|
Depth |
149 mm |
Information About 3RV1031-4EA10
The Siemens 3RV1031-4EA10 SIRIUS Manual Motor Protector/Circuit Breaker is a component designed for motor protection within industrial applications. It operates within a current setting range of 22-32A and is classified under Motor Protection CLASS 10. The device does not include an auxiliary switch and features an instantaneous short-circuit release (N-release) with a capacity of 416A.
This circuit breaker is configured as a 3-pole device with a maximum current rating of 32A and a maximum voltage rating of 575V AC. It belongs to Size S2 category and is equipped with screw connections for ease of installation. The device offers standard switching capacity, ensuring reliable performance in controlling electrical circuits.
The primary function of the 3RV1031-4EA10 circuit breaker is to protect motors from overload conditions and short circuits. Its robust design and adherence to industry standards make it suitable for various industrial applications where motor protection is essential.
By incorporating features such as the current setting range, instantaneous short-circuit release, and standard switching capacity, this circuit breaker offers comprehensive protection for motors, enhancing the safety and efficiency of industrial operations. The absence of an auxiliary switch simplifies the device's design and installation process, making it suitable for diverse industrial environments.
Manufacturer information
Siemens: A renowned global manufacturer, leading in technology, engineering, and innovation across diverse sectors for a sustainable future.
