3VA5210-6ED61-0AA0 | Siemens 100A 2-Pole 480V 3VA5 Thermal-Magnetic Molded Case Circuit Breaker
- Regular price
- $1,389.00
- Sale price
- $1,389.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: 3VA5210-6ED61-0AA0
Description
The Siemens 3VA5210-6ED61-0AA0 is a 2-pole 3VA5 molded case circuit breaker designed for reliable line protection in low-voltage power distribution systems. Rated for 100A and up to 480V AC, it features a thermal-magnetic trip unit (TM210) that ensures dependable overload and short-circuit protection. With a breaking capacity of 65 kA at 480V, this circuit breaker provides high-performance protection for commercial and industrial electrical applications.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Siemens |
| Category | Circuit Breakers |
| Part Number | 3VA5210-6ED61-0AA0 |
| Subcategory | Molded Case Circuit Breakers |
| Series | 3VA5 UL |
| Frame Size | 250 |
| Number of Poles | 2 |
| Rated Current (In) | 100 A |
| Voltage Rating | 480 VAC |
| Breaking Capacity | 65 kA @ 480 VAC |
| Trip Unit Type | TM210 – Thermal Magnetic |
| Protection Type | Overload (Ir = 100A), Short-Circuit (Ii = 10 x In) |
| Mounting Type | Fixed |
| Connection Type | Without Connection (no terminals installed) |
| Operating Frequency | 50/60 Hz |
| Compliance Standards | UL 489, IEC 60947-2, RoHS |
| Country of Origin | Czech Republic |
| Packaging Dimensions (L x W x H) | 245 x 150 x 160 mm |
| Weight | 1.9 kg (4.19 lb) |
Information About 3VA5210-6ED61-0AA0
The 3VA5210-6ED61-0AA0 is part of the Siemens 3VA5 UL Series, a modern range of molded case circuit breakers built to meet UL and IEC standards. Designed with a compact frame size of 250, it delivers efficient protection and high interrupting capacity in confined panel spaces. This model incorporates a fixed thermal-magnetic trip unit (FTFM), offering accurate long-time and instantaneous fault detection without user adjustment. Ideal for use in switchboards, control panels, and machinery distribution, it ensures dependable circuit isolation and long operational life under demanding electrical conditions.
Key Features:
- Rated Current: Supports continuous operation at 100A for stable circuit protection.
- High Breaking Capacity: Withstands fault currents up to 65kA at 480V for secure system operation.
- Thermal-Magnetic Trip Unit: Combines thermal overload and magnetic short-circuit protection for efficiency.
- Fixed Settings: Permanently set protection parameters reduce complexity and enhance reliability.
- 2-Pole Configuration: Suitable for single-phase or DC protection requirements.
- Compact Frame Size: Frame 250 design fits easily into tight installations and control enclosures.
- UL and IEC Certified: Fully compliant with UL 489 and IEC 60947-2 standards.
- Durable Construction: Designed for long service life in industrial and commercial environments.
The 3VA5210-6ED61-0AA0 delivers the reliability and precision required for modern low-voltage power protection systems in demanding electrical infrastructures.
