4145J42-G01 | General Electric Isolated E/I Board

Description

The General Electric 4145J42-G01 Isolated E/I Board is designed to enhance the reliability and safety of industrial systems by isolating electrical inputs and outputs. This board provides robust protection against signal interference, ensuring precise data transmission and stable performance in critical control applications.

Technical Specifications

Information About 4145J42-G01

The General Electric 4145J42-G01 Isolated E/I Board is an essential component designed to provide robust isolation between electronic circuits and input/output (I/O) signals in industrial control systems. This board ensures signal integrity and system protection by isolating different sections of the control system, which helps to prevent electrical interference and potential damage from voltage spikes or ground loops.

Operating with an input voltage of 24V DC, the 4145J42-G01 board is compatible with a range of industrial power supplies and equipment. This voltage specification aligns with many standard industrial systems, making the board suitable for integration into various applications where reliable isolation is required.

The board is engineered to function effectively within a wide operating temperature range of 0°C to +70°C. This capability allows it to perform reliably in diverse environmental conditions typical of industrial settings, including those where temperature fluctuations are a factor. Whether installed in a climate-controlled environment or in more extreme conditions, the 4145J42-G01 maintains its operational integrity and performance.

For storage, the 4145J42-G01 is rated to endure temperatures from -40°C to +85°C. This broad storage temperature range ensures that the board remains in good condition during periods of inactivity or between installation phases, safeguarding it from environmental extremes that could potentially impact its functionality.

Humidity tolerance is another key feature of the 4145J42-G01. The board can operate effectively in environments with a relative humidity range of 5% to 95% non-condensing. This makes it suitable for use in various industrial environments where humidity levels can fluctuate. The non-condensing specification helps to prevent moisture accumulation on the board, which could lead to electrical issues or corrosion.

The primary function of the 4145J42-G01 is to provide electrical isolation, which is crucial in protecting sensitive electronic components from potential interference and damage. By isolating electronic and I/O signals, the board helps to ensure that high-voltage or noisy signals do not affect the integrity of the low-voltage control signals, thereby enhancing the overall reliability and performance of the control system.

The board's design incorporates high-quality materials and components to achieve its isolation function. It features advanced isolation technologies that ensure minimal signal degradation and high isolation resistance, thereby contributing to the stability and accuracy of the control system.

In summary, the General Electric 4145J42-G01 Isolated E/I Board is a critical component for industrial control systems requiring reliable isolation between electronic circuits and I/O signals. Its compatibility with a 24V DC input voltage, along with its wide operating and storage temperature ranges and humidity tolerance, makes it a versatile and dependable choice for various industrial applications. By providing effective isolation, the board enhances the protection and performance of control systems, ensuring their reliable operation in demanding environments.

Manufacturer information

General Electric (GE) is a multinational conglomerate founded in 1892, based in the United States. It operates in various industries, including aviation, healthcare, renewable energy, and power. GE is known for its innovations in technology, manufacturing, and infrastructure solutions.
